3 impedance calc mistakes (we catch these on 60% of jobs):

1. Nominal Dk — FR4 shifts to 3.8 at 10GHz (15% error)
2. Etch factor — 5mil trace = 4.2mil after etch
3. Soldermask adds 2-4 ohms on microstrips

Fix inputs, not tools.

#PCBDesign #DFM

[AtlasPCB @Atlas_PCB]

Worldwide Robot Conference👍
PCB is everywhere.

[AtlasPCB @Atlas_PCB]

Tg150 vs Tg170 decision:

Board >1.6mm + 2 or more reflow cycles? Spec Tg170.

Tg150 risks delamination by the 3rd pass. Premium is only 2-4 cents/cm2. Cheaper than a respin.

#PCBDesign #DFM

[AtlasPCB @Atlas_PCB]

6L impedance cost tip: try asymmetric prepreg (1080-2116-3313). Same Z0, 8-12% less laminate cost.

Catch: check CTE balance for bow. Ask your fab if they model asymmetric stackups — the answer tells you a lot.

#PCB #HighSpeedPCB

[AtlasPCB @Atlas_PCB]

Ask your fab about panel utilization before finalizing board dimensions.

Moving from 98x48mm to 95x45mm fit 2 extra boards per panel on a recent job. 15% unit cost drop. Zero design compromise.

Small trim, big savings.

#PCB #DFM

[AtlasPCB @Atlas_PCB]

Ai is coming 👉high speed PCB is in high demand.
Telecom is growing👉high frequency PCB is in high demand too.
～🔥🔥～

[CTO ROBOTICS Media @ctorobotics]

This tiny robot moves like a real animal. 🐾🤖

Meet Kame, a compact open-source, 3D-printable quadruped robot designed to reproduce animal-like gaits and movements.

The original Kame was developed by Javier Isabel at BQ Innovation Lab, using 3D-printed parts, Arduino/ESP8266 electronics and eight servos.

Small robot. Simple hardware. Surprisingly expressive movement.

Would you build one yourself? 👀

🎥 Media: Kame Robotics

⚠️ This content is shared for informational purposes only. CTO Robotics Media is a media platform and does not own or develop the technology shown. Credit belongs to the original creators.

#Robotics #OpenSourceRobotics #3DPrinting #QuadrupedRobot #DIYRobotics #Engineering #Automation #Innovation

[AtlasPCB @Atlas_PCB]

Here you go. RF boards.

[AtlasPCB @Atlas_PCB]

super thick PCB. Guess what is designed for.. 👀

[AtlasPCB @Atlas_PCB]

ENIG with 3-6um Ni and 7-9% phosphorus passes 5x reflow for most BGA above 0.4mm pitch.

ENEPIG adds $0.80/sqft — only needed for <0.4mm pitch or wire bonding.

Ask your fab's black pad rate before upgrading.

#PCBDesign

[AtlasPCB @Atlas_PCB]

Thermal relief on a 20A rail with 2oz copper adds 15-40 milliohms. That's a 300mV drop your regulator never expected.

Direct connect on high-current pads. Always. Unless your assembler literally can't solder it.

#PCBDesign #DFM

[AtlasPCB @Atlas_PCB]

PCB Fabrication. 7*24 hour factory production time.

Upload Gerber file to get fast quotation.
1) instant quotation: you can select specs and the place order online.
2) custom quotation: you can specify more details and special requirements.

https://t.co/FgqUNVZkCc

[AtlasPCB @Atlas_PCB]

Fab note template (cuts revision emails 40%):

MATERIAL / STACKUP / IMPEDANCE / FINISH / SPECIAL / TEST

6 lines covers 90% of what your fab needs upfront. No more 3-email chains. Copy and use it.

#DFM #PCB

[AtlasPCB @Atlas_PCB]

PCB and PCBA. We are specialized in complex PCB manufacturing. Shoot us with your PCB designs.

[AtlasPCB @Atlas_PCB]

Our 6L impedance reference:

SE 50ohm: 4.1mil, ±7%
Diff 100ohm: 4/4mil, ±8%
Dk 4.2 @10GHz (Megtron 6)
TDR coupon every panel

3,000+ panels/month. Bookmark for your next stackup review.

#SignalIntegrity #PCB

[AtlasPCB @Atlas_PCB]

PCB fabrication and PCB manufacturing! 7×24 hours production time. We work hard. What’s the point of working hard—-having a fun time with family afterwards. 🥳

[AtlasPCB @Atlas_PCB]

Advanced PCBs. Ready for shipping! Guess what are the final products that they’ll turn into.

[America News @AmericaPartyX]

🚨 CHINESE COMPANY UNITREE REVEALS ALL-TERRAIN WHEELED ROBOT

The military potential of this technology is obvious.

Europe is falling far behind China. It’s becoming scary.

[AtlasPCB @Atlas_PCB]

Hi! Advanced PCB of any kind. We are specialized in making complex boards. Shoot us with your innovative PCB board designs. 💡

[AtlasPCB @Atlas_PCB]

7*24 factory runtime. RF/HDI/Rigid-flex,etc. Quick turn!
