FRAME (Steel Structures)

تصميم وتحليل وإخراج الهياكل المعدنية وإشراف على التنفيذ
Steel Structures Designs| Analysis | Modeling | Detailing

[FRAME (Steel Structures) @Engintips]

Massive PEB Hangar Design with Advanced Engineering Specifications
Dimensions: Width: 112 m , Length: 140 Clear Span:
56 m free span without any internal columns
Design Loads:
Dead Load: 0.11 kN/m²
Live Load: 0.6 kN/m²
Collateral Load: 0.15 kN/m²
Wind Speed:164km/h

[FRAME (Steel Structures) @Engintips]

Siesmic Load : Zone 3 According to UBC97

[FRAME (Steel Structures) @Engintips]

Design & Analysis of Multi-Storey Steel Structures

Completed the structural design and analysis for 4 multi-storey steel buildings, focusing on safety, efficiency, and code compliance.

Project Highlights:

- Total area: 158 m² ( each Storey )
- Structural system: Steel frame

[FRAME (Steel Structures) @Engintips]

تصميم وتحليل لهيكل معدني ( سُلم Step staircase ) بناء على الأكود :
Design and analysis for steel structure (Step Stair case ) according to :

- ASCE 7-22 &7- 16 for Loading
- AISC 360 |2016 for Steel Design .
- EN 1993 for Connection Design .
- IBC 2018 for Deflection Limits.

[FRAME (Steel Structures) @Engintips]

Design and analysis for (Canopy)

Design Codes , Standards and References :
- ASCE 7-22 &7- 16 for Loading.
- AISC 360 |2016 for Steel Design.
- ASCE 7-16: for wind load.
- EN 1993 for Connection Design .
- ASCE 7-2022 Section 2.4.1 for Deflection Limits .

[FRAME (Steel Structures) @Engintips]

Design Cat Ladder According to
:
ASCE 7-22 &7-16 for Loading
AISC 360 | 2016 for Steel Design
AISC 370 | 2016 for Stainless Steel Design
EN 1993 for Connection Design
#تصاميم
#تنفيذ
#هياكل_معدنية
#هياكل_استيل
#ستينلس_ستيل

[FRAME (Steel Structures) @Engintips]

تصميم هيكل لوحة إعلانات
Billboard Sign Structure Design..

#لوحات_اعلانية
#قواعد_طاقة_شمسية
#هناجر
#هياكل_معدنية

[FRAME (Steel Structures) @Engintips]

Handrail Design According to ASCE 7-2016 | Analysis Using Dlubal RFEM | Connection Design with Hilti PROFIS Engineering
I recently completed the structural design and verification of a Floor-mounted handrail system in accordance with ASCE 7-2016
#StructuralEngineering

[FRAME (Steel Structures) @Engintips]

Design Multi Storey Steel Structure

[FRAME (Steel Structures) @Engintips]

نمذجة وتصميم هيكل حامل للالواح الشمسية عدد 60 لوح حجم 700 وات ...
Modeling & Design Solar Structure

#هناجر
#قواعد_طاقة_شمسية
#مظلات
#تصاميم
#هياكل_معدنية
#ظله
#تفصيل
#لحام
#hangars
#steel_structures
#solar_structures
#shading
#Car_shading
#welding
#fabrications

[FRAME (Steel Structures) @Engintips]

هيكل الواح طاقة شمسية على شكل هنجر
تصميم وتنفيذ : فريم للخدمات الهندسية

#قواعد_الواح
#هناجر
#تصاميم
#تنفيذ
#تفصيل
#لحام
