[PCB Arts @PcbArts]

Something BIG is coming to the edge👀
Camera-heavy. Fast. Built for industry.
See it at @embedded_world , Hall 2 | Booth 2-539
#embeddedworld #ew26 #EdgeAI

[PCB Arts @PcbArts]

New toy for our production: A Pick-and-Place Machine🙌 We’re now able to handle customer projects fully in-house, making us far more flexible and significantly faster in production🚀 #PnP #SMT

[PCB Arts @PcbArts]

@MacroWorld21 Sorry, it should read "RoadInspect relies on the Sony IMX900 sensor combined with Vision Components’ GMSL image streaming" 😅

[PCB Arts @PcbArts]

Most dashcams record. #RoadInspect understands.
A triple-camera system for next-gen vehicle vision with wide outdoor coverage, IR-enabled driver monitoring, and low-latency #GMSL imaging. It's not just a dashcam – it's a platform for #EdgeAI in #mobility🚘 #dashcam

[PCB Arts @PcbArts]

@MacroWorld21 Thanks! And yes, it relies on the Sony IMX900 sensor combined with GMSL image streaming and the necessary vision components. Here are the specs:

[PCB Arts @PcbArts]

rc_visard NG by @roboceptionGmbH : Jetson Orin, stereo vision & passive cooling in one compact housing – no fan, no host PC. We supported with high-speed multilayer #PCBDesign (signal integrity, #EMC , thermal layout) and scalable electronics production💪 #RobotVision

[PCB Arts @PcbArts]

Did you know? USB-C isn’t just for charging – it can detect water in the port and disable power to prevent shorts or corrosion. It uses CC pins + smart firmware. Rarely well-implemented, but we’ve built it deep into #Helium for real-world reliability. #USBC #WaterDetect

[PCB Arts @PcbArts]

@ns_schoe The USB-C controllers usually have moisture detection functions, so they measuring the resistance between two pins in the Connector and deactivate the power delivery, when moisture detected. Same like in Smartphones „Liquid detected in USB-C Connector, charging not available“.

[PCB Arts @PcbArts]

Rugged ≠ just a sealed box. Many “great” systems fail in the field due to small physical issues: vibration, dust, heat, cable stress. With #Helium, we designed for the real world – IP67, screw-lock connectors, flexible cooling. Built for the edge!

[PCB Arts @PcbArts]

@ns_schoe Yes, it has an o-ring directy integrated:

[PCB Arts @PcbArts]

@observie @MehdiHacks you can, here: https://t.co/qvbXSu4TFE

[PCB Arts @PcbArts]

@moddedLimes It's build for use-cases on trucks or cars, means shock tests up to 30g and sinus vibrations up to 4g.

[PCB Arts @PcbArts]

To evaluate #BGASSD technology, we tested an adapter prototype in M.2. Measuring just 16 × 20 × 2 mm, it removes connectors for more durability, simplifies production, and improves energy efficiency for longer battery life. A compact storage solution where every mm counts💪

[PCB Arts @PcbArts]

Our PCB Arts Tech Meet-up is back – more community-driven than ever🎉
Network, share insights & pitch your own project in a 5-min slot!
Let’s shape the future of embedded systems together🚀
Participation is free, but spots are limited: https://t.co/c2MxjckU9d
#Networking #MEETUP

[PCB Arts @PcbArts]

Get your tickets for free: https://t.co/RtBDhVOlSI

[PCB Arts @PcbArts]

Calling Tech Enthusiasts Attending Embedded World 2024, join us at the PCB Arts Tech Meetup on 10.04.2024 in Nuremberg. It will be a good networking event from engineers for engineers. See you there!

[PCB Arts @PcbArts]

4x FPD Link III 2,5Gbit/s per Link, will be available soon on our EdgeKit. But not just the hardware, also the drivers for FPD Link and the @AlliedVisionTec (avt_csi2) drivers, with all the higher level Frameworks (VimbaX) will come pre-installed on the lastest #NVIDIA JetPack.

[PCB Arts @PcbArts]

We´ve uploaded the design files of our FPD Link serializer board for the Raspberry Pi global shutter camera module. This is still a work in progress, but verification should be finished soon 🙌
https://t.co/0iueLn3a8d

[PCB Arts @PcbArts]

@bis0nmakinm00 @_photony_ Yes, this is the magic of FPD Link. You just need one coax for everything.

[PCB Arts @PcbArts]

Exciting to discover the capabilities of FPD Link -transmitting up to 4,16 GBit/s of data, supporting I2C communication, GPIO's, powering devices up to 10 watts over a single coax cable and that with cables up to 15m long.
