usaduct

USA Duct

[usaduct @usaduct]

Literally the first time this contractor had ever held the #trumpf 301 #seamcloser. #ductwork #pittsburghlock #avoidhearingloss #sheetmetalfab #trumpf301

[usaduct @usaduct]

A machine that does for Duct Liner the same thing the #plasmatable did for Metal.....and interfaces to autodownsize the Liner for the corresponding metal piece. This is a No Brainer #viconplasmaautomation #ductliner #ductfabrication #reducingwaste #innovations #automation

[usaduct @usaduct]

#flexibleductconnector specified on commercial jobs to isolation noise and vibrations from air handlers like this massive one at the new airport under construction in New Orleans #squareelbow #turningvane #rectangularduct #hvacductwork #ductwork #canvasconnector

[usaduct @usaduct]

Likely the most significant innovation in history of #HVAC #ductfab is the #plasmatable — unfortunately it was also a dagger in the heart of the #sheetmetal Layout Tradesman as a vocation. #hvacductwork #sheetmetallayout #lockformer #viconplasmaautomation #sheetmetalautomation

[usaduct @usaduct]

Nested #TDF profile L Sections with the Male Pitts Flange running Longitudinal #commercialductwork #alabamaconstruction #sheetmetalfab #sheetmetalfabrication

[usaduct @usaduct]

Aluminum Ductmate 45 Flange Fabricated into two Frames holding Duro Dyne’s MBX Canvas Connector To control vibrations and noise from a large blower nearby #noiseisolation #ductwork #durodyne #ductmate #canvasconnector

[usaduct @usaduct]

Some Square to Round Transitions larger than others like this heavy gauge Aluminum one that’s to be installed on a massive Plenum Box pulling 60,000 #CFM's from an Air Handler #ductwork #airhandlingunit #aluminumfabrication #aluminumfabrication #comfortsystemsusa #smlawrence

[usaduct @usaduct]

This is what “spoiling” the field crew looks like while saving Job Site install costs and providing better looking ductwork in the process. #ductworkinstallation #prefab #rectangularduct #gulfcoastair #pensacolaconstruction #comfortsystemsusa

[usaduct @usaduct]

Up close and personal with JM’s RC Duct Liner. When it comes to Acoustics and Thermals, external wrap cannot touch internally lined duct. #johnsmanville #insulation #ductliner #jm #ductfab

[usaduct @usaduct]

Johns Manville Spiracoustic cut out for insulated spiral duct fittings
#ductfab #jm #johnsmanville #spiracoustic #ductfittings

[usaduct @usaduct]

An army of TDF profile Duct formed on a Vicon Full Wrap Coil Line, Pitts vertical Seamcloser and Dual Head Corner Inserter. D&N Duct Solutions Miami FL
#ductfab #tdf #coilline #vicon #plasmaautomation #pittsburghseam

[usaduct @usaduct]

Typically #fittings this tight are made with #ductmate flange. This shop shows that running it on their #TDX machine isn’t a problem. #TDF profile on transverse, Pittsburgh’s #hammeroveredge front and center on the #longitudinalseam #ductfab #ductfitting #vicon #plasmaautomation

[usaduct @usaduct]

When a job has the space to work with, #radiuselbows are often the choice for the #ductdesign plans instead of Square backed with #turningvanes. Shown here in the new Airport under construction in New Orleans #ductfab #ductdesign #radiuselbow #NOLA #neworleans

[usaduct @usaduct]

Need a reminder why cost of fabrication is only one of several considerations for the Sheet Metal Contractor? #ductfab #sheetmetalcontractor #rfknox #spiralpipe

[usaduct @usaduct]

Sealing the #ductwork in the #fabshop instead of on the #jobsite is the future of commercial #HVAC Duct #rectangularduct #hvacduct #ductsealing #ductworkinstallation

[usaduct @usaduct]

Large #rectangularduct externally wrapped. Vapor Barrier sealed withy 6” overlap, white #mastic and #meshtape #weldpins #commercialductwork #merv8 #iaq #insulatedduct #mechanicalcontractors #sheetmetalfab #jacksonville

[usaduct @usaduct]

1/8” Aluminum Plate designed and fabricated for a Freon Removal system by Park Central Metal Fab Atlanta #freon #aluminumwelding #aluminumplate #specialtymetalfabrication #metalfab #atlantawelders

[usaduct @usaduct]

#offset Drop Cheek Elbow. Typically these #fittings are made with #ductmate flange however this was large enough that the shop was able to run with #TDC as the transverse connections. #pittsburghlock on all Longitudinal seams and insulated with 1” #JM RC #ductliner #sheetmetalfab

[usaduct @usaduct]

One step of several in Cutting out taps for Double Wall Spiral Pipe with JM Unfaced Liner wrapped around solid inner wall. D&N Duct Solutions Hialeah FL. #spiralpipe #doublewallspiralduct #johnsmanvilleinsulation #ductfab #jmliner #johnsmanville #doublewall #spiral

[usaduct @usaduct]

4 lengths of WDCI J Flange connected with 4 Corners into the familiar Slide on Frame that is Ductmate. This frame will slide over the end of a 30-1/2” x 30 1/2” Square Duct #ductmate #squareduct #transverse #wdci #jflange #ductmate #ductfab
