Cleveland Punch

Industry leader in punches, dies, shear blades and other ironworker component parts since 1880. Proudly manufactured in the USA. Phone: [phone]

[Cleveland Punch @ClevelandPunch]

Double step punch in action💥 As you can see, we have a modified stripper because the standard stripper would crush the legs of the channel, but at the end of the video you can see there is no deformation to the legs🥳

[Cleveland Punch @ClevelandPunch]

〰Shape possibilities are endless at CPD.〰

[Cleveland Punch @ClevelandPunch]

Testing out a double step punch on our Piranha ironworker! The double step reduces the body diameter and adds length without weakening the punch. This is useful for punching angle, channel and I-beam. We manufactured the piece of angle with bolts to work as our stripper.

[Cleveland Punch @ClevelandPunch]

We are closed Monday July 5th in observance of Independence Day but you can still order online or send us an email & we will get back to you ASAP!
.
From everyone at Cleveland Punch & Die we wish you a safe & happy 4th of July!🇺🇸

[Cleveland Punch @ClevelandPunch]

Punching louvers is a breeze with the oversize attachment on our P50! Here we are creating 3” form down louvers in 14G material. Louvers are most commonly used to create vents for generators, lockers&even hot rod cars! Our engineers are ready to help with your next louver project

[Cleveland Punch @ClevelandPunch]

Starting to get our displays ready for @fabtechexpo 2021! After no show last year, we can’t wait to see everyone!!
.
Want to see how we formed these louvers on our Piranha?
.
Make sure you follow us because that video is dropping tomorrow!

[Cleveland Punch @ClevelandPunch]

We’re punching 1/2” round holes in 2” x 2” x 1/4” angle with our Edwards 55 ton using a standard punch and an offset die. Watch until the end to see just how close these holes are to the other leg of the angle!

[Cleveland Punch @ClevelandPunch]

Who’s ready for a video of the offset punch & die punching angle?! 🙋🏽‍♂️
.
Keep your eyes peeled this week👀

[Cleveland Punch @ClevelandPunch]

Depending on what machine you’re using & what size pipe you’re notching, we can possibly make you a set up like this! This is a dual pipe notch on our Amada Marvel Sahinler MSIW60D. One side notches 1-1/4” schedule 40 and the other side notches 1-1/2” schedule 40.

[Cleveland Punch @ClevelandPunch]

-CPDS0012 F770/F740 set
-CPDS0122 F9/F43 set
-CPDS0123 F13/F51 set
-CPDS0015 SR20K/F155 set
Don’t see your tooling? Shoot us a message, we have custom sets available too! Click the #linkinbio to check out all the sets & what sizes they include!

[Cleveland Punch @ClevelandPunch]

Punch & Die Sets!! Looking to replace worn out tooling? Or looking for a start up set of punches and dies? We’ve got you covered! The following sets are available for purchase on our website:
-CPDS0002 F16/F55 set
-CPDS0008 F16/F59 set
-CPDS0003 F20/F59 set
-CPDS0009 F26/F62 set

[Cleveland Punch @ClevelandPunch]

May we always honor and never forget the reason for this holiday weekend🇺🇸

[Cleveland Punch @ClevelandPunch]

Notching 2” schedule 40 pipe on our Edwards 55 ton ironworker💥
.
Don’t forget, we stock 1”, 1-1/4”, 1-1/2” and 2” schedule 40 & schedule 80 tooling!
.
The housing & striker punch are in stock too, you could be notching pipe tomorrow, saving time & money!🤑

[Cleveland Punch @ClevelandPunch]

When I first saw this punch, I thought they were using the square as a guide to punch a round hole where there was currently a square hole. Boy was I wrong!🤦🏻‍♂️ This punch and die is used to build trailers & notching out this radius will allow for pipe to fit snug against the angle

[Cleveland Punch @ClevelandPunch]

Scotchman Pipe Notch Tooling~We’re notching 1-1/4” schedule 40 pipe on our @scotchmanind 50514-EC. In addition to the housing and striker punch we also stock 1”, 1-1/4”, 1-1/2” and 2” in schedule 40 & schedule 80! We would love to see your tooling in action, be sure to tag us!

[Cleveland Punch @ClevelandPunch]

Punching 3 holes at one time? Easy-peasy with this custom attachment for a new Piranha P-50! Our customer needed to punch three 1⁄4” holes 1-3⁄8” apart in 2” x 2” x 1⁄4” aluminum angle. Our team got to work and designed this triple punch & die attachment with a fixed stripper.

[Cleveland Punch @ClevelandPunch]

Piranha P-65 mandrel for 2-3/4” OD x .045” tube. We’re punching three 9/32” holes 90° apart. These will be used to create exhausts🏍

[Cleveland Punch @ClevelandPunch]

Our customer is shearing Unistrut all day, every day and wanted to use the Geka Hydracop 50 they had in the shop already. They sent in a sample of their Unistrut and our engineers got to work. Now our customer is saving time & money cutting the Unistrut on their Geka Hydracrop 50

[Cleveland Punch @ClevelandPunch]

Don’t forget, for the Piranha machine we stock 1”, 1-1/4”, 1-1/2” and 2” tooling in schedule 40-90° and schedule 80-90° along with the housing and striker punches!

[Cleveland Punch @ClevelandPunch]

Did you ever wonder how you’re supposed to line up the pipe notch cut at exactly 180°? We slowed this video down to a #slomo so you can easily see it. The lines that run along the edge of the cutting tool are to line up your pipe, how handy is that?!
