GradConn, Ltd

Making exceptional coaxial cable assemblies and connectors for the electronics industry 💧 Home of the Nautilus range of IP Rated coaxial solutions 💧

[GradConn, Ltd @GradConn_Ltd]

Remove the risk.
Using only genuine I-PEX micro connectors is very important to us, and you...
Rest assured that our cable assemblies won't let you down on performance or price. https://t.co/4t7UJNlP0Q

[GradConn, Ltd @GradConn_Ltd]

📢We are pleased to announce our new global partnership with @ipexconnectors for their MHF® series. Stay tuned for more new products in this exciting collaboration. Find details and try the MHF® series on your next design 📷 https://t.co/KrICDU5zbZ

[GradConn, Ltd @GradConn_Ltd]

We've relaunched our website to include the most awesome cable assembly builder! It really is as easy as ABC. Simply select connector A (SMA, TNC, BNC, I-PEX and more), then connector B, and finally select your required 'C' (cable). Go to https://t.co/qkL1coXwh7 and give it a try

[GradConn, Ltd @GradConn_Ltd]

You need IP-rated coaxial connectors and assemblies specified for excellent environmental protection, but how will they perform in the field?

Download our independently conducted Extended Environmental Simulation test results: https://t.co/kVzNqg9aHY

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Our MMCX is a micro-coaxial connector for PCB connections requiring integrity, strength and flexibility. Featuring snap-on mechanism with 360° rotation, available as SMA cable assemblies or standalone PCB mount variants, tested for up to 500 mating cycles. https://t.co/i79DQvFi5x

[GradConn, Ltd @GradConn_Ltd]

We are often asked if Hirose U.FL and I-PEX® MHF® micro coax connectors are compatible. Our experience, backed up with independent tests, allows us to provide a definitive answer - Yes!

Learn more: https://t.co/UtZxaOP7kp

#coax #connectors #hirose #IPEX #gradconn

[GradConn, Ltd @GradConn_Ltd]

Only IP67/68 panel-mount TNC on the market

Ideal for applications requiring high levels of ingress protection whilst needing a flange mounted option. Cable assemblies supplied with wide a selection of connectors for end 2, including I-PEX & Hirose. https://t.co/3wZ3X58HU8

[GradConn, Ltd @GradConn_Ltd]

IP67/68 rated PCB mounted SMA connectors ideal for applications where the comms module doesn't include an RF interface connector and protection against liquid ingress is critical. Available in straight & right angle and standard & reverse polarity options. https://t.co/a3N1wGjyG6

[GradConn, Ltd @GradConn_Ltd]

Our IP67-rated caps prevent a build-up of moisture, dust, and debris in coaxial connectors when unmated. Available in SMA, N-type, and TNC versions, the brass-alloy caps are nickel or gold-plated and are available with/without a chain tether. https://t.co/GNrpuajHWb

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Our Nautilus waterproof RF cable assemblies offer protection from tampering with front-mounted connector options. Assemblies available from SMA, TNC and N-type to a variety of interface connectors including I-PEX. https://t.co/fKE58pJ4XG

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Our Nautilus range of IP67/IP68/IP69K coaxial cable assemblies are designed to withstand extremely harsh environments where gold-plated brass is not resilient enough.

Available in assemblies with a variety of RF connectors - including I-PEX: https://t.co/H0UjEph3UX

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Brass bodied caps not robust enough your application?

Consider Nautilus stainless steel options. SMA and TNC protective caps guard against corrosion and the build-up of moisture, dust, and debris in the connector when unmated. Learn more: https://t.co/rdvQhbxNlx

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Ultimate shock, vibration, dust & water protection

Our Nautilus range of IP67/IP68 SMA coaxial cable assemblies is now available with latching I-PEX MHF® I LK micro connectors - ideal for applications where connection integrity is paramount. https://t.co/NJl6HLlyTU

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Our I-PEX® MHF® range now includes secure MHF® 4(L) micro connectors for use with IP67/IP68/IP69K SMA coaxial cable assemblies.

Nine ready assemblies here: https://t.co/1pBaJSikQt
To build your own assembly: https://t.co/JJcqbNT9fV

#gradconn

[GradConn, Ltd @GradConn_Ltd]

Uninterrupted signal & data without crosstalk

Prevent interference across multiple RF outputs with enhanced environmental protection for demanding applications with our Nautilus IP67/IP68 SMA & TNC to MMCX or I-PEX® cable assemblies.

Learn more: https://t.co/YaOpNr73Sx

[GradConn, Ltd @GradConn_Ltd]

Minimum PCB space, maximum performance

I-PEX® MHL® 5L wire-to-PCB coaxial micro connector paired with our Nautilus IP67/IP68/IP69K SMA bulkhead connectors offer the ideal cable assembly for challenging conditions. Ten variants are available now:
https://t.co/lhuH2Pn0U2

[GradConn, Ltd @GradConn_Ltd]

Secure PCB to SMA coaxial connections.

Our I-PEX® MHF® range now includes secure MHF® 4L LK micro connectors for use with IP67/IP68/IP69K SMA coaxial cable assemblies.

Build your own assembly: https://t.co/ee0KqaoWfc
View the full range: https://t.co/eqTyShWZFF

#cableassembly

[GradConn, Ltd @GradConn_Ltd]

GradConn's massive range of board-to-board connectors for parallel PCB mating can be baffling. But don't worry, our board to board stacking calculator is a step by step system to find the perfect matting connector design solution.

Give it a go: https://t.co/S6pK9QwMep

[GradConn, Ltd @GradConn_Ltd]

Our all-new coaxial cable assembly builder helps you create your perfect assembly. With a great selection of options and clear visual and detailed information, you can build an assembly quickly and with ease. Check it out: https://t.co/MvR6wM7XLy

[GradConn, Ltd @GradConn_Ltd]

Waterproof without a cap?

Our Nautilus stainless steel, IP67, IP68 & IP69K SMA cable assemblies are designed and tested to withstand extremely harsh environments. Learn more: https://t.co/uF6UoyGo01

#IP67 #IP68 #IP69K #SMA #nautilus #gradconn
