Replacement monitor for my DVK-3

[Gryphon Laboratory @GryphonLab]

Profi 5.02 more photos

[Gryphon Laboratory @GryphonLab]

Oh yeah, we are cooking now

[Gryphon Laboratory @GryphonLab]

An interesting approach to implementing protection against hacking/copying/analysis (?)
The bits are rearranged when connecting the ROM, and bits in the firmware are also rearranged accordingly.

[Gryphon Laboratory @GryphonLab]

Profi 5.02 processor board.
Now fully repaired and working fine with all 1MB of RAM.

[Gryphon Laboratory @GryphonLab]

He is dead, Jim.
Also, those 565RU7I chips my tester can’t fully test, for whatever reason all chips have some kind of glitches on its memory cells. Weird.

[Gryphon Laboratory @GryphonLab]

Poisk-2 with Soviet i8086 (К1801ВМ86) CPU is working fine with ISA16 VGA adapter and multicard 💪
Finally found a suitable case to fit a full size AT motherboard

[Gryphon Laboratory @GryphonLab]

Assembled a programmer for old tiny Soviet PROMs

[Gryphon Laboratory @GryphonLab]

POISK-2 - [replica of] late Soviet IBM XT clone with i8086 processor and 2MB RAM. Quite interesting machine, way more capable than POISK-1.
It would be quite tricky to find a case for such AT board..

[Gryphon Laboratory @GryphonLab]

Finally found missing memory boards for my Elektronika-60M
#pdp11

[Gryphon Laboratory @GryphonLab]

Consul 256 - Czechoslovakian paper terminal (“type” printer + keyboard), which I do hope to connect to my Elektronika-60M, a soviet clone of PDP-11

[Gryphon Laboratory @GryphonLab]

Just look at that
It’s IBM XT clone with NEC V20 turbo i8088 CPU clone.
I am definitely assembling that

[Gryphon Laboratory @GryphonLab]

gitlab

[Gryphon Laboratory @GryphonLab]

No waaay! It’s still alive, even after all of that… incredible

[Gryphon Laboratory @GryphonLab]

Late evening play with old MFM HDDs.
Surprisingly those two old Seagates are still working

[Gryphon Laboratory @GryphonLab]

Tried to clean up as much as I can, with compressed air. It looks now decent (not fully clean), but it’s better than before. Unfortunately platters look very worn out, not sure if the disk is alive at least…

[Gryphon Laboratory @GryphonLab]

Just look at this cool device that fell into my hands!

[Gryphon Laboratory @GryphonLab]

Fujitsu Siemens Scaleo E HTPC
Finally repaired this piece of junk - had one broken PWM controller for SB, and one transistor…
Works decent, but the unit is missing the original PCIe ADD2 video output card which could output analog signal to built-in SCART connector

[Gryphon Laboratory @GryphonLab]

Toyota Crown Majesta
Old digital dashboards are my weakness~
