Paul B. Jacob High Voltage Laboratory

Paul B. Jacob High Voltage Laboratory at Mississippi State University serves as an independent, non-industrial, university center for high voltage engineering

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Up close, in the dark: the exact moment an arc forms when approach distance breaks.

36kV energized rod, grounded probe closing in. This is what "electricity doesn't need contact" actually looks like. ⚡

#HighVoltage #ElectricalSafety #MSStateEngineering

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

You don't have to touch an energized conductor for electricity to reach you.

This demo at HVL: rod energized to 36kV, grounded probe moves closer. Before contact, the air itself starts to ionize. That sound is the safety margin breaking.

#HighVoltage #ElectricalSafety #MSState

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Before any voltage: the boom gets wiped with denatured alcohol,even clean-looking fiberglass can have a film that lets current track over the surface. Then we ramp voltage all the way to a 720kV overvoltage proof, watching leakage current continuously.

#HighVoltage #Utilities

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

⚡ 1.1 MV lightning strike to a scaled navy ship model. Testing whether its lightning protection draws the bolt to itself.

Lightning protection testing at the Paul B. Jacob HVL.

#HighVoltage #PowerEngineering

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

⚡ 27kV fuse cutout, pushed past its rated current. Watch the fuse link heat up, resist, then melt.

Overcurrent testing at the Paul B. Jacob HVL.

#HighVoltage #PowerEngineering

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Introducing EeSho, the original electric-eel mascot created for the Paul B. Jacob High Voltage Laboratory!
#MississippiStateUniversity #HighVoltageLab #ElectricalEngineering #EngineeringDesign #STEM #CanvaDesign #PaulBJacobHVL #EeSho

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

AC flashover test at the Paul B. Jacob High Voltage Laboratory!
Equipment: 27kV class fuse cutout
Flashover voltage: 82kV
#HighVoltage #PowerEngineering #ElectricalEngineering #DistributionSystems #MississippiState

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Dielectric Breakdown: When Insulation Reaches Its Limit at 200 kV at Paul B. Jacob HVL at MSU
⚡ #HighVoltage #ElectricalEngineering #Dielectric #MississippiState #Dielectric

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Jacob's Ladder ⚡ At 85 kV, an arc climbs upward as rising heat expands the gap it must jump. Named for the biblical stairway to the heavens. Simple demo, powerful physics. #HighVoltage #HVLab

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

A long time ago, in a lab not so far away...
Full interview with Dr. Wallace on life inside HVL now on YouTube: https://t.co/BIjvnWdbR7
#HighVoltage #Tesla #StarWars

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Storm meets grid⚡🪾🌳🌲 . Simulating a tree branch contacting a live 25kV distribution line, which is one of the most common real-world causes of outages.
#HighVoltage #PowerGrid

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Inside the Paul B. Jacob High Voltage Laboratory — impulse testing, insulator testing, and a 1.2M volt strike on a scaled airship model. Largest university-operated HV facility in North America.

#HighVoltage #MSU #ElectricalEngineering

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

⚡ Meet the Paul B. Jacob High Voltage Lab at MSU, the largest university-operated HV facility in North America! 3,000 kV impulse generators. Partial discharge detection. Lightning-tolerant materials. 📷 https://t.co/Rm2EeZpHy0 #HighVoltage #EngineeringResearch #MSState

[Paul B. Jacob High Voltage Laboratory @HailStateHVLab]

Leakage current test at 0.73 million volts.

AC incremental leakage current testing of Bucket truck from 80kV to 0.73 million volts

#highvoltage #powerengineering #hailstate #msstate
#electricalengineering
