Good CFD Saves Good Ideas #SimulationFriday
Apparently this is what AI thinks my typical workday looks like. It isn't completely wrong. Checkout Stallion 3D to accelerate your early designs from concepts to efficient aircraft.
➡️ https://t.co/VX7RIBd6jK
My exact ChatGPT prompt: "can you use this picture to make an overly-ai picture of me solving a CFD problem with Stallion 3D. Just for a fun post, maybe."
It's 1938 but something is not quite right at NACA 🤔
Can you spot it?
The researcher is reducing wind tunnel data and verify calculations for what would become Report No. 647.
Clue ➡️ https://t.co/WtPq5adfp5
#SimulationFriday#Aerodynamics#FluidDynamics#WindTunnel#CFD
#ComputationalFluidDynamics
ONERA M6 Wing on NASA (.gov): Section 4 (y/b = 0.8)
Why does Stallion 3D capture the double shock at Section 4?
Learn more ➡️ https://t.co/VX7RIBd6jK
Stallion 3D gets its high accuracy from cubes & right rectangular prisms throughout the CFD domain, even at the boundaries. The novel boundary treatment preserves the high-accuracy of the automatic Cartesian grid scheme throughout the computational domain. Transonic results exhibit sharp shockwaves and extremely accurate solutions while running locally on your Windows 10/11 laptops.
⚽ #SimulationFriday FIFA inspired.
A soccer ball was simulated in Stallion 3D at 67 mph (30 m/s) with 600 rpm (10 Hz) of spin to examine the Magnus effect responsible for a bending free kick.
The simulation predicted:
• Side Force: 5.72 N (1.29 lb)
• Total Drag: 5.70 N (1.28 lb)
• Lift: −0.333 N
The streamlines show the asymmetric wake generated by the spinning ball, producing the lateral force that curves the trajectory. Although simple in appearance, predicting this behavior requires resolving the interaction between boundary-layer separation, rotation, and wake development around the ball.
Sometimes CFD predicts an aircraft. Sometimes it predicts a free kick.
Learn more about aerodynamics ➡️ https://t.co/VX7RIBd6jK
#SimulationFriday #CFD #Soccer #FIFA #Aerodynamics #Stallion3D #MagnusEffect #Engineering
A soccer ball is simulated in Stallion 3D at 67 mph (30 m/s) with 600 rpm (10 Hz) of spin to examine the Magnus effect responsible for a bending free kick.
Watch now ➡️ https://t.co/Dqebn9cFFj
#FIFA#FIFAFEVER2026#aerodynamics#WorldCupFinals
Transonic Airfoil Analysis Tool #SimulationFriday
I wrote this code several years ago as a stepping stone towards MultiElement Airfoils. Here, I worked out a 2nd order Van Leer flux vector splitting scheme that exhibited a sharp shock. I incorporated an automatic elliptic grid generation method. Note, the Cp has just 1-point along the shock waves ⚡
Learn more about VFPlus➡️ https://t.co/VX7RIBdE9i
#airfoiltools #aerodynamics #airfoil #cfdsoftware #transonic
eVTOL Transition Strategy
I used Stallion 3D to understand a preliminary strategy for an eVTOL transition.
Learn more ➡️ https://t.co/sp1gZSsLfm
Method - Build a table of aerodynamic parameters with Stallion 3D and build a flight dynamics plant model for the transition strategy. The above page shows a simplified transition model, a hexacopter. Use Stallion 3D to generate the aerodynamic parameters to optimize the strategy.
The cure for channel surfing ✈️
CFD ➡️ https://t.co/VX7RIBdE9i
It's difficult to switch channels after an accidental click to Top Gun. Simulated at Mach 2 & 20,000 ft. F-14 and F-5 models from #Thingiverse
Runtime about 1-hour with Stallion 3D on my 8-core laptop 💻
#aerodynamics #CFDSimulation
SSAM 5th Generation Model Mesh
Geometry via OpenVSP Airshow. Simulation at Mach 1.8 & 40,000 ft.
Aerodynamics via Stallion 3D ➡️ https://t.co/VX7RIBd6jK
Solution details ➡️ Automatic Cartesian grid (no cut cells); 2nd order Van Leer FVS; local time steps; 2-equation k-e turbulence model; 3D RANS; local OpenMP acceleration on Windows 11 laptop. Two cases ran concurrently each with 8 threads. ~ 900,000 cells
eVTOL Transition Strategy
I used Stallion 3D to understand a preliminary strategy for an eVTOL transition.
Learn more ➡️ https://t.co/sp1gZSsLfm
Method - Build a table of aerodynamic parameters with Stallion 3D and build a flight dynamics plant model for the transition strategy. The above page shows a simplified transition model, a hexacopter. Use Stallion 3D to generate the aerodynamic parameters to optimize the strategy.
How I Developed a Suite of Airfoil Tools #SimulationFriday
Step 1. Airfoil analysis using a linear-strength panel method & stall model.
Step 2. Interactive multi-element airfoils tool with Step 1 solver.
Step 3. Step 1 GUI with O-grid & Euler/Van-Leer FVS method
Step 4. Step 2 workflow with Euler /Van-Leer FVS and Cartesian grid
The strategy was to develop a modern suite of airfoil tools for engineers and students. This was done progressively with one step verifying the next.
Learn more ➡️ https://t.co/BBwCOn79Nq
#CFD #aerodynamics #aerodynamicssoftware
A soccer ball is simulated in Stallion 3D at 67 mph (30 m/s) with 600 rpm (10 Hz) of spin to examine the Magnus effect responsible for a bending free kick.
Watch now ➡️ https://t.co/Dqebn9cFFj
#FIFA#FIFAFEVER2026#aerodynamics#WorldCupFinals
⚽ #SimulationFriday FIFA inspired.
A soccer ball was simulated in Stallion 3D at 67 mph (30 m/s) with 600 rpm (10 Hz) of spin to examine the Magnus effect responsible for a bending free kick.
The simulation predicted:
• Side Force: 5.72 N (1.29 lb)
• Total Drag: 5.70 N (1.28 lb)
• Lift: −0.333 N
The streamlines show the asymmetric wake generated by the spinning ball, producing the lateral force that curves the trajectory. Although simple in appearance, predicting this behavior requires resolving the interaction between boundary-layer separation, rotation, and wake development around the ball.
Sometimes CFD predicts an aircraft. Sometimes it predicts a free kick.
Learn more about aerodynamics ➡️ https://t.co/VX7RIBd6jK
#SimulationFriday #CFD #Soccer #FIFA #Aerodynamics #Stallion3D #MagnusEffect #Engineering
I googled "how to analyze a UAV with Stallion 3D" 🛩️
Surprisingly, the Google AI gave the exact steps 🧐
In the age of AI good documentation can 10X.
Watch UAV video 📽️ https://t.co/SjFIEaqA4Q
Keywords: #SimulationFriday, aerodynamics, CFD, computational fluid dynamics
Use Stallion 3D for aircraft analysis. It's well documented and ideally suited for quick and accurate aircraft analysis on your Windows laptop or desktop.
Learn more ➡️ https://t.co/c7QkDcXr6n
#aerodynamics#UAV#computationalfluiddynamics#simulationfriday
I googled "how to analyze a UAV with Stallion 3D" 🛩️
Surprisingly, the Google AI gave the exact steps 🧐
In the age of AI good documentation can 10X.
Watch UAV video 📽️ https://t.co/SjFIEaqA4Q
Keywords: #SimulationFriday, aerodynamics, CFD, computational fluid dynamics
