REFORM Trirex – Let's take a closer look today – the 360° swiveling dresser
Due to the swivel range of 360°+ height adjustment, the dresser can be positioned precisely and accurately to produce contours and profiles of any size.
REFORM Trirex – Let's take a closer look!
Today: The cross-axis head
You are wondering how to produce a perfect spherical shape of large double spherical roller bearings?
The Trirex 3000 is the choice for this grinding task. Due to the development of a cross-axis head, it is possible to grind spherical roller surfaces with the highest precision in a short time. Bearing rings up to a height of 700mm can be machined on the Trirex 3000.
Equipped with a hydrostatic rotary table, the TRIREX 3000 convinces with a cross axis head, dressing spindle and swiveling dresser right next to the rotary table, and easy programming via parameter input.
#PSS#REFORM#Bearings#grindingmachine#machinery#manufacturing
Big work pieces need big machines!
Even with the biggest REFORM machines, we meet the high accuracies requested by the bearing industry.
Our Trirex 3000 is the ideal match when it comes to processing work pieces of up to 3000 mm (swing diameter 3400 mm)!
Fast Facts:
-Removal rate of up to 100 cm³/min
-Accuracies: Flatness < 2.5 µm, plane parallelism < 2.5 µm
-Repeatability of down to 2 µm
You want to learn more? Stay tuned and we will soon post the video here!
This week we had a film crew in house to spotlight our RS machine.
The RS machine is our hybrid solution for high removal rates while achieving high accuracies at the same time
You were wondering what a "small" footprint with highest precision finishing means to us? Look at the picture below
The NEO 5 has a footprint of approx. 9m² (incl. tool changer) and solves highest surface finishing requirements for workpieces up to Ø 600 mm.
The larger RI Series is able to process work pieces up to Ø 1800 mm. Both machines are used in many industries to process stators, high precision coupling parts (curvic coupling), bearings & gear parts, turbine parts, and aerospace components - just to mention a few applications
Our HSG is designed for high precision grinding and deburring tasks for turbine blades of engine rotors and gas turbines. Two highlights of the HSG are the calibration block and the on-board master.
#Reform, #PSS, #grinding, #machining
The opening of this state-of-the-art manufacturing facility in Troisdorf, Germany, strengthens the SPF Division even further. In the future, REFORM, ISOG, and KEHREN machines will be built at this site.
Stay tuned for further updates! #PSS, #Kehren, #Reform, #StrongerThanEver
Now stronger than ever before:
#PSS Surface and Profile Finishing Division with a new location in Troisdorf, Germany
We are proud to announce that we found a great location close to the current location of KEHREN. #PSS, #Kehren, #Reform, #grinding, #StrongerThanEver
The NEO 5 accepts the most challenging processing tasks of workpieces up to 600 mm diameter and table load of 1000kg. A swiveling head of +95°/-90° is another highlight as well as its very compact design of only approx. 9m².
Learn more: https://t.co/eYYQXUoth8
#PSS#Kehren
Check out the newest addition to the product portfolio of KEHREN , the 5-axis vertical grinding center NEO 5!
Besides surface grinding (ID and OD), cone and sphere grinding, the NEO 5 is suitable for (pre) turning and milling, serration and curvic coupling.
Turbine parts, aerospace components, Stators, high precision coupling parts (curvic coupling), bearings and gear parts are just a few applications to be processed on this machine.
