This semester, Choco-Fab made silicone chocolate molds of the OSHE logo and the MTU Husky!

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

ATX Power Supply: In this video, we will explain the high-level design of our power supply. For more in-depth information, go to https://t.co/ENrpeE4WvP to see our work logs and project overview page.

(Video too large for twitter)
https://t.co/1De5Z0ykah

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

Recyclebot Spring 2024 Update: This semester, Recyclebot has been hard at work improving our heating and extruding process.

(Video too large for twitter)
https://t.co/VdDtNMiE6g

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

PCB is in and components are being soldered for Zeusaphone!

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

KeWee Energy Meters is working with a new power monitoring chip! This chip, the ACS37800, communicates over I2C. Team members Liam (left) and Caleb (right) are shown debugging communications with the chip, and responses are shown in the Arduino IDE.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

Tune in as Alex explains the components of our custom temperature sensor!

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

We're the Electric Viola team, and this semester we've worked on the physical design of the viola, the pickups, and a metronome and tuner that will be encompassed by the viola.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

BREAD BUNS has been making progress on our bar code system. Here is our mountable remote scanner for tracking boxes on conveyors.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

Introducing a new project in OSHE - IRL Subtitles! This project aims to create wearable technology that can display real-time subtitles from the environment to the user. Stephen, Luc and Luke have been hard at work on the second iteration of the printed circuit boards.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The Laser Tag Team: Got the auxiliary board for the Teensy all soldered up!

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

BREAD DAQ is an open source data aquisition device that integrates into the bread BREAD (Broadly Reconfigurable and Expandable Automation Device) ecosystem.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

ReStruder is trying to make recycled 3D printer filament more accessible by reducing the required tolerances

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

Here is the result of our first official test.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

First official test of the ChocoFab chocolate assembly system! The melted chocolate successfully moved through the tube to the mold, demonstrating the system's operational capability. While the chocolate bar needs cooling, this marks the start of customizable chocolate bars.(1/2)

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The Bird Attractant and Deterrent team has made some serious progress! They have completed a box that is better than the first version and looks great! Hopefully the birds really like this one.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The Localized Lyme Disease Fighting team will have their Tick Repellent Administration System (TRAS) completed shortly. The TRAS includes a real time clock module, an SD card module, a HX711 amplifier, and a load cell to collect data regarding the amount of mice that enter.

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

KeWee Energy Meters: This is our current circuit configuration with our newly printed PCB. #pcb #kicad #circuit

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The Tesla Team: Tesla coil circuit assembly in full swing! #circuitry #coil

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The Laser Tag team now has a shell to start testing electronics in, that has been 3D printed from the OSHE lab printers! #lasertag

[Michigan Tech Open Source Hardware Enterprise @MTU_OpenSource]

The ATX Power Supply team has completed a SPICE simulation of a buck converter. Shown is the circuit diagram, filtered output, and method of control for switching. Using this 12 volt to 5 volt converter we were able to see a 3% ripple at 20 Amps! #power #circuit
