Video Microscope Selection: Differences Between 2D and 3D Imaging.
Using 3D microscopy to observe solder beads and pin soldering anomalies on SMT components.
#Microscope #VideoMicroscope #EOCMicroscope

[EOC Microscope @MicroscopeEOC]

EOC at #OVCEXPO2026 (May 18-20,China- Wuhan). Showcasing microscopy & intelligent inspection for Light+AI era. ✨
#HuaxianOptics#microscope#cpo

[EOC Microscope @MicroscopeEOC]

Semiconductor wafer thickness measurement with 25nm precision. #SemiconductorChip #Microscope #Wafer #Profilometer

[EOC Microscope @MicroscopeEOC]

Optical communication manufacturers use EOC high-definition microscopes for visual inspection of chip bonding. Magnification ranges from 50X to 1000X, with 20-megapixel resolution for real-time imaging.
#Microscope #SemiconductorChip #OpticalCommunication #CPO #MPO

[EOC Microscope @MicroscopeEOC]

High-density connector pin material inspection – Observing copper surface morphology at 200X–3000X magnification. No detail escapes detection. #High-Speed Cable Server #Microscopy #Material Analysis

[EOC Microscope @MicroscopeEOC]

What’s inside a 245μm PCB hole?

Diameter: 245μm
Depth: 501μm
Edge: clean, no burrs ✅
Inner wall: uniform texture, no residue ✅
Copper bonding: tight, no cracks ✅
One tiny hole —
the whole story of PCB reliability.
Follow me for more 🔬#microscope#PCB

[EOC Microscope @MicroscopeEOC]

The 3-day business trip to Bac Ninh, Vietnam has been completed. I discussed the upcoming production plans and the number of microscopes to be used with the Vietnamese client.#microscope

[EOC Microscope @MicroscopeEOC]

When inspecting electronic components for appearance defects under a microscope, choosing the right lighting is crucial.
#VideoMicroscope #Microscope #AppearanceInspection

[EOC Microscope @MicroscopeEOC]

During the production of fiber array products for optical communication, the dimensional angles are held to very strict standards. High-precision measurement equipment is used, achieving an angular measurement accuracy of 0.1 degrees. #opticalmodule
#microscope

[EOC Microscope @MicroscopeEOC]

During the production process, wafers need to be magnified and observed under a microscope. The laser wafer microscopy system performs laser ablation on defective products, including cutting etched circuits.
#Wafer microscope #Wafer Laser Etching #microscope

[EOC Microscope @MicroscopeEOC]

Flatness Inspection of AI Server Liquid Cooling Modules
It performs rapid multi-point distance measurement on the copper block surface, with the software automatically determining OK/NG. The measurement accuracy is 0.005mm.#AI Server Liquid Cooling Unit#microscope

[EOC Microscope @MicroscopeEOC]

The Chinese Spring Festival is celebrated by everyone. It symbolizes reunion and good fortune. Wishing everyone a happy Spring Festival!

[EOC Microscope @MicroscopeEOC]

@semivision_tw The PCB inside the optical module

[EOC Microscope @MicroscopeEOC]

What does a cardiovascular stent look like? Let’s take a closer look under the microscope. With high-definition magnification, the subtle connections of the vascular stent become clearly visible.#microscope

[EOC Microscope @MicroscopeEOC]

@semi_journal_jp CPO-pcb

[EOC Microscope @MicroscopeEOC]

Through high-definition microscopic imaging, observe appearance defects on the optical module PCB board. Accurately magnify and detect subtle flaws.#microscope#optical m'odule

[EOC Microscope @MicroscopeEOC]

Using a super-depth-of-field microscope, the three-dimensional data of the chip and substrate are captured under high magnification, allowing for real-time measurements from any point on the substrate to the four corners of the chip surface.#microscope#chip

[EOC Microscope @MicroscopeEOC]

@semi_journal_jp Package Height

[EOC Microscope @MicroscopeEOC]

@semivision_tw The optical module chip is observed magnified under a microscope.

[EOC Microscope @MicroscopeEOC]

High-definition video microscopy of industrial crystal sugar magnified 30X-200X. Particles are distinct, enabling direct dimensional measurement.#microscope
