BGA joint failures? 5 design fixes:

1. Epoxy-filled capped vias under BGA
2. IPC-7351 pad sizing
3. NSMD pads for stronger joints
4. Thermal relief on large copper pours
5. No tall parts shielding BGA during reflow

Full details in infographic 👇

#BGA #PCBDesign

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

PCB surface finish quick guide:

🔹 HASL: cheapest, not for fine pitch
🔹 ENIG: best for BGA, flat, 2x cost
🔹 OSP: low cost, flat, short shelf life
🔹 Immersion Tin: great for press-fit, whisker risk
Auto/medical default: ENIG.

#PCB

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

@a2e1534 Good call doing prototypes first — op-amp noise and stability can surprise you on the first spin. What's your target quantity for the prototype run?

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

4-layer PCB stackup cheat sheet:

1️⃣ SIG-GND-PWR-SIG: general purpose
2️⃣ GND-SIG-SIG-GND: high-speed, best EMI
3️⃣ SIG-GND-SIG-PWR: mixed-signal

Rule: always pair signal with adjacent ground. Which do you use? 👇

#PCBDesign

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

PCB testing: Flying probe vs bed of nails.

🔹 Flying probe: no fixture, best for prototypes, 2-5 min/board
🔹 Bed of nails: custom fixture, best for volume, ~10 sec/board

We use flying probe for prototypes, bed of nails for volume. 100% nets tested.

#PCB

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

Inside our factory: AOI line in action.

Every board gets 100% AOI — catches solder bridges, missing parts, misalignment, tombstoning.

Full report with every batch. Quality isn't an add-on.

#PCB #QualityControl

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

When choosing a PCB manufacturer, what matters most to you?

Vote 👇

[Bean | PCB & PCBA Manufacturing CN @MrBeanDou]

5 DFM mistakes to avoid:

1. Annular rings <0.15mm → cracked pads
2. Silkscreen on pads → poor solderability
3. Copper <0.3mm from edge → exposed copper
4. Unfilled via-in-pad → BGA voids
5. No fiducials → SMT misalignment

Save this list 📌

#PCBDesign #DFM
