Office Custom Design Plus@die design consultant

Supporting sheetmetal die design of general progressive dies and manual-transfer dies as consultants.25 years part production and die making experience.

[Office Custom Design Plus@die design consultant @OfficeCustom]

Fine weather, hot fans #Indy500

[Office Custom Design Plus@die design consultant @OfficeCustom]

Ready to win, Takuma! #indy #texas #NTT

[Office Custom Design Plus@die design consultant @OfficeCustom]

A little different shape. #ua #airline #united

[Office Custom Design Plus@die design consultant @OfficeCustom]

How about this? Using Japanese tool. Design engineering will approve. #die #design #consult

[Office Custom Design Plus@die design consultant @OfficeCustom]

Level 1-Nail hole non pre-hole, does not have straight surface. Is it OK for you? #diedesign #consulting #sheetmetal

[Office Custom Design Plus@die design consultant @OfficeCustom]

#die #sheetmetal #press recently the die designer does not have knowledge about cost comparison, reading 2D drawing, machining process, assembly. Design will be effective to you company. We can support

[Office Custom Design Plus@die design consultant @OfficeCustom]

Many bending line makes spring back, that will be out of spec. Before making die design, should consider about that like including spring back or adjustment method. #diedesign #Consultant #sheetmetal

[Office Custom Design Plus@die design consultant @OfficeCustom]

@atsushi_terada いいことありますように。

[Office Custom Design Plus@die design consultant @OfficeCustom]

Bending line, galvanized surface is a little rough. Looks not big deal. That happens from material, but if add coating punch, better than this. #diedesign #sheetmetal #press #consultant

[Office Custom Design Plus@die design consultant @OfficeCustom]

@JoeyThe_Hamster @united You can arrive your destination. Save your trip. Hope Your feeling lighter. UA6200 is still hot by bad air conditioning.

[Office Custom Design Plus@die design consultant @OfficeCustom]

UA6200 BNA-IAH No air conditioning,
Do you want to kill us? #ua #United #airline

[Office Custom Design Plus@die design consultant @OfficeCustom]

Tomorrow, go to my vendor to see runoff at the first hit. Tuesday, Wednesday, see other dies at another die vendor. In this case , some trouble happens at my facility when I am out of office. It is common sense. #diedesign #trial #stamp

[Office Custom Design Plus@die design consultant @OfficeCustom]

Trial stamping check by web cam. Too difficult, because cannot hear correct noise, dies might be crying why you cannot find trouble. That is made several trial times for picking error up. #diedesign #consulting #trial #sheetmetal

[Office Custom Design Plus@die design consultant @OfficeCustom]

Got part design changing request. Start to study if it’s possible to modify from current die. How to modify? How much need cost? How many days for modification? It is too darkness road. #diedesign #consulting #modification #Change

[Office Custom Design Plus@die design consultant @OfficeCustom]

Checked hole size using pin gauge. Does not match part drawing, how to inspect this sample at vendor? Cannot see what his effectivity is in this project. #diedesign #runoff #trial #measure

[Office Custom Design Plus@die design consultant @OfficeCustom]

“Runoff” I do not like this word using at vendor m, because they don’t have inspection against irregular operation. Trial shows some conditions, that will be happened at production. #diedesign #consult #sheetmetal #stamping

[Office Custom Design Plus@die design consultant @OfficeCustom]

At the trial, should see except correct production. For example, if die makes misdeed, what happens? Before starting production, should know.
If you does not have experience or not have resources, we can support. #diedesign #consulting #troubleshooting

[Office Custom Design Plus@die design consultant @OfficeCustom]

Die design does not have same design because 1. Designer is different 2. Designer has improved
3. Part can be made any operation.
We should know which way the best way is. #diedesign #consultant

[Office Custom Design Plus@die design consultant @OfficeCustom]

Die design shows close position. But at production, die is opening and closing. That means we need to check open position and coil feed interference for preventing from finding after running off. #diedesign #consult #progressive #check

[Office Custom Design Plus@die design consultant @OfficeCustom]

When have similar die, easy to find trouble and how to improve. Those dies shows correct conditions. If each die provides different information, dies are suspected that have too many issues from die design. Almost come from design. #diedesign #consulting
