Open Source Arms maintains an open technical database of standardized testing, manufacturing practices, and technical data packages of tested firearm designs.
Updated Posted:
11/22/26 -Changed OSA-15-CHARGE-HANDLE-BODY, had missing feature which left charging handle unconstrained in Z.
Until the drawing package is released updates will be in file description on the sea and through screen grabs like this. Alpha release gets dwg.
@BrassKickerMFG Not much, the Buffer Cartridge and Raceway or Internal Cartridge pull out the rear and quarter turn to separate thus releasing buffer and spring. In the future there is room for activities.
Note: Use the charging handle to 'release' the internals after the rear pin is pulled.
@rjward1775 Yes, this scales down, the PCC version is short enough to fit within a HF press to form in Printed tools, and is a single part per side no removable handguard. This is exactly a path we hope to wear in with time. Good eye.
@rjward1775 You got me dying with that, in a way yes? Some creative license on Chris Cross's masterpiece. Thanks. Yep, Laser/Water cut, bend, and rivet, or someone could mod files and weld, or any number of fab techniques.
A rebellion built on hope.
free files
plastic parts
nuts and bolts
barrel made with a bucket of water
hair product can
Now you have hope and a 3D printed integrally suppressed submachine gun.
