The VSG200 is officially in stock and available now! ⚡

Range of 100 kHz to 20 GHz, 40 MHz of real-time streaming #bandwidth, and a fully overhauled #VSG software with even more features and functionality. Ready when you are. 🔗 https://t.co/9UEWIlS7xw

[Signal Hound @SignalHound]

@MehdiHacks Also well-suited for the SP145 and BB60! Just in from the software team 😉

[Signal Hound @SignalHound]

Pulse Analysis is now live in #Spike. Visualize AM and FM vs. time, auto-detect CW, chirp, and Barker pulses, de-interleave up to five emitters, and characterize every pulse to IEEE 181 standards. Cross-correlation pulls signals out of the noise, autocorrelation finds repeating structures, and the #SM200 and #SM435 series capture up to 160 MHz so nothing gets missed. 𝙏𝙝𝙞𝙨 is the pulse characterization tool your workflow has been missing. ⚡

[Signal Hound @SignalHound]

@MehdiHacks @Elektor Cool feature!!

[Signal Hound @SignalHound]

@mwfoutch1 🤝🤝🤝

[Signal Hound @SignalHound]

Senior Engineer Justin Crooks talks how the flagship #SM200 series spectrum analyzers started out with a complex layout, but after testing became the simpler two-board solution it is today. A terahertz per second sweep rate and exceptional #dynamicrange were worth the trial and error. ⚡

[Microwaves & RF @MicrowavesRF]

Multichannel I/Qanalysis from @SignalHound provides a powerful, integrated way to see and measure complex RF behaviors across multiple inputs. https://t.co/nODtbmgyiW

[Signal Hound @SignalHound]

If you're missing some serious firepower in your lineup, we've got you covered.
🟢 SM200C: 100 kHz to 20 GHz, 160 MHz #bandwidth
🟢 SM435C: 100 kHz to 43.5 GHz, #sweeps at 1 THz/sec at 30 kHz RBW
🟢 PCR4200: 100 kHz to 20 GHz, four-channel, phase coherent receiver
🟢 VSG200: 100 kHz to 20 GHz, arbitrary I/Q sample rates from 12.5 kSPS to 51.2 MSPS

Shop now 🔗 https://t.co/EwlFZIc522

[Signal Hound @SignalHound]

Missed the drop of our #VNA white paper? Inside we cover:
🟢 VNA fundamentals
🟢 Why portability is a must-have
🟢 How to leverage modern circuit tech for faster, better #RF measurements
Download it now 👇 https://t.co/X4lUifZaK0

[Signal Hound @SignalHound]

@Friis25 Yes, with the BB60D it is a single channel with a focus on spectral purity. With the VNA400, it is 4 channels with a focus on phase and amplitude stability!

[Signal Hound @SignalHound]

Justin breaks down what's actually inside our #VNA400: two independent shielded sources covering two separate #frequencyranges, a 4-channel ADC for simultaneous sampling on both forward and reverse ports, and a USB interface keeping it all compact and powered.

[Signal Hound @SignalHound]

NEVER too many spectrum analyzers.

[Mehdi @MehdiHacks]

How many spectrum analyzers do you need?
Me: yes.

[Signal Hound @SignalHound]

@MehdiHacks Yes 🥰

[Signal Hound @SignalHound]

This Memorial Day, we pause to remember and honor those who have lost their lives in service of our country. They have made the ultimate sacrifice.

[Signal Hound @SignalHound]

@Friis25 Late to seeing this but

[Signal Hound @SignalHound]

Big spectrum coverage. No mystery pricing. The #SM435C offers 100 kHz–43.5 GHz range, 160 MHz I/Q streaming, 110 dB dynamic range, and a built-in sub-octave preselector for serious #RFengineering. > https://t.co/QSBZV1Nl3s

[Signal Hound @SignalHound]

@JamesMcPherson The FPGA is unfortunately not programmable by the user, but I might add "extremely capable" to my list of descriptors for the SM435 😉😂

[Signal Hound @SignalHound]

When paired with the #SM435C, the GPIO connection lets the SM435C's FPGA drive the switch directly. No middleware, no extra hardware, and nothing adding latency between the analyzer and the switch equals a fundamentally faster automated test setup. ⏩

[Signal Hound @SignalHound]

@kodizhuk Yes to Linux, not yet for Mac! Maybe @MehdiHacks can help you out if you have a Mac.. 😉

[Signal Hound @SignalHound]

Your next pocket-sized powerhouse. 🤝
🟢 100 kHz to 14.5 GHz
🟢 200 GHz/sec #sweepspeeds and stream up to 40 MHz of calibrated I/Q #data
🟢 Internal #GPS

[Signal Hound @SignalHound]

@aussetg 😂😂

[Signal Hound @SignalHound]

@Friis25 The VSG200? Here's a link for ya: https://t.co/Pta2detT3m
And yes we will be! Find us at Booth 22016 with that VSG ⚡️

[Signal Hound @SignalHound]

@MehdiHacks 😍😍😍
