SkyJuice

Founder of Angstronomics, an independent publication covering the Semiconductor Industry

[SkyJuice @SkyJuice60]

Angstronomics draws the line on RDNA 3!

We detail key specifications of Navi31, Navi32 and Navi33 that were finalized in 2020 and have not changed since!

We also highlight some architectural changes including OREO😋

WGP, Cache and die sizes inside!
https://t.co/n2qB7KiiBg

[SkyJuice @SkyJuice60]

@SteakandChickn For reference, Genoa-X is already over 146B xtors.

[SkyJuice @SkyJuice60]

@SteakandChickn Hey, the 2019 Mac Pro also used a big Broadcom switch for its slots, and that was PCIe Gen 3

[SkyJuice @SkyJuice60]

Apple WWDC 2023
Mac Pro: M2 Ultra Mac Studio with a big switch to enable 6x internal PCIe4 slots for $3000 more

Apple Vision Pro: M2 ON YOUR FACE! (and R1 sensor co-processor) for $3500 in 2024
2 hour battery life with a battery dongle

[SkyJuice @SkyJuice60]

This shows the two fans cooling said M2 on your face

[SkyJuice @SkyJuice60]

The long-delayed Intel-powered Aurora supercomputer fails to make the June 2023 TOP500 list!

"Promising early performance results on the Aurora hardware will be shown" at #ISC23 later today.

[HPC Guru @HPC_Guru]

61st #Top500 revealed at #ISC23

#Frontier lives to be dethroned another day!

No change in rankings of the Top 10 #supercomputers, although Frontier, LUMI & Leonardo improved their HPL score

https://t.co/NvaPmAfbJl

#HPC #AI @ISChpc @top500supercomp

[SkyJuice @SkyJuice60]

Looks like @ServeTheHome is about to check out the 25.6T Broadcom Tomahawk 4 switch! Here's a clearer image of the LGA 8371 socket of the BCM56990 found on ebay:

[Patrick J Kennedy @Patrick1Kennedy]

Bryan just took this photo of me. This is probably the biggest chip I have ever installed with over 8000 pads. If you are thinking it is an Ampere Altra Max package, it is much larger.

[SkyJuice @SkyJuice60]

@SprayOnCopper @IanCutress SRF-SP has only 1 compute tile.
Lisa Spelman is holding an SPR-XCC wafer.

[SkyJuice @SkyJuice60]

Emerald Rapids XCC
2 dies of Intel 7, about 770mm² each!

[SkyJuice @SkyJuice60]

@SquashBionic @Locuza_ STH: "I missed the <5 second clip of the chip close up."😔

[SkyJuice @SkyJuice60]

@PinaJr Orin Nano uses the exact same die, just with most of it disabled.

[SkyJuice @SkyJuice60]

NVIDIA's Orin is bigger than M1 Max!

TechanaLye tears apart an AGX Orin and finds a large ~455 mm² die with 17B transistors on Samsung 8nm.

M1 Max on TSMC5 is smaller but packs 3.3x the transistors.
M2 packs more transistors in 1/3rd the area!

Our die annotation is here!

[テカナリエ清水 @techanalye1]

左 NVIDIA ORIN
右 Apple M1 Max

[SkyJuice @SkyJuice60]

And of course RTX 4000 SFF has 4x mDP1.4 vs 0 on L4.

Doing a rough estimate using RTX 4080 Laptop efficiency curves would put the RTX 4000 SFF at around 10k in TimeSpy Graphics.

A similarly priced RTX 4080 desktop card pulling 320W is almost 3x faster.

[SkyJuice @SkyJuice60]

#GTC23 RTX 4000 SFF vs NVIDIA L4
48SM vs 58SM AD104
20GB 320GB/s vs 24GB 300GB/s
1.56GHz vs 2.04GHz
19.2TF vs 30.3TF
70W vs 72W
Dual slot blower vs Single slot passive (system airflow)
$1250 vs $????

[SkyJuice @SkyJuice60]

#GTC23 And here is Grace Hopper!
Doing a quick compare vs GH100's 814 mm², it looks like Grace on TSMC 4N is about 730 mm²!
Pretty large for a 72-core CPU.

[SkyJuice @SkyJuice60]

More details on Grace Superchip efficiency.

"NVIDIA Grace is sampling now with production in the second half of the year." - Mar 2023

"Grace CPU Superchip and Grace Hopper Superchip are expected to be available in the first half of 2023." - Aug 2022

https://t.co/Cnu36ujWrn

[SkyJuice @SkyJuice60]

#GTC23 1st public reveal of Grace Superchip!

[SkyJuice @SkyJuice60]

#GTC23 DGX Cloud
Each instance of DGX Cloud features eight NVIDIA H100 or A100 80GB Tensor Core GPUs for a total of 640GB of GPU memory per node.
- Scalable to multiple nodes
DGX Cloud instances start at $36,999 per instance per month

[SkyJuice @SkyJuice60]

#GTC23 Keynote:
NVIDIA H100 on TSMC 4N uses 89 photomasks

[SkyJuice @SkyJuice60]

56c 3495X OC
Enermax 360mm AIO (700W thermal limit)
4.0GHz 1.0V: R23 96960 (throttles after hitting 102°C in 3 seconds)

EK 480mm Custom Loop
4.7GHz 1.13V: R23 114699 (hits 95°C in 6 seconds)
Mainboard pulls over 1000W at peak
https://t.co/xa2Kfa5SYw

[SkyJuice @SkyJuice60]

56c SPR 3495X OC
1.2v 40x ratio
98708 R23
End of run: 1326W, -21°C (LN2)

[SkatterBencher @skatterbencher]

Live 3DMark CPU Profile WR Attempt by Elmorlabs (feat. Xeon w9-3495X) https://t.co/FETmdx1D5o via @YouTube

[SkyJuice @SkyJuice60]

@RGBbenchmark Easily over 1500W!

[SkyJuice @SkyJuice60]

Overclocked 24c Sapphire Rapids
50k R23
Prime95 4.6GHz 630W 90°C (480mm rad)
ASUS W790-ACE

[Michal Simonek @FlanK3rXS]

Xeon w7-2495X Sapphire Rapids Live Overclocking (Day 1) https://t.co/uyWYkE6UP1 prostřednictvím @YouTube
