koldwater

Providing Training Applications for the Electrical Controls Industry for 31+ years. Quality instructional software for PLC training, HMI training, VFD, etc.

[koldwater @TechnicianEDU]

New at Koldwater!
The PLCLogix 500 PLC Simulator and the 5000!
See https://t.co/yuSVOzz0aR

#plcsimulator

[Don at BIN95.com @IndTraining]

PLC Troubleshooting Tips: OTU, JSR, and MCR causing ill logic.

We just made a short visual walkthrough video for this OTU/JSR/MCR topic, plus added a couple of bonuses. Check it out at ▶️ https://t.co/pHOPRNGJ75

#RSLogix5000 #PLCTroubleshooting #rslogix #allenbradley #plc

[Don at BIN95.com @IndTraining]

Environmental conditions can flip the standard "#PLC Physical Failure Probability" hierarchy on its head:

• Foundries ➡️ Metal dust on Backplanes.
• Machining ➡️ Fluids short Input cards.
• Wire Mfg. ➡️ High voltage spikes fry unprotected CPUs.

#maintenance #troubleshooting

[Don at BIN95.com @IndTraining]

Control Panel Design TIP:

Extend the PLC communication port outside the panel and include a power outlet for the technician's laptop. But place both in a locked enclosure so only authorized personnel may access.

https://t.co/XV5atfhkUP

#ControlPanelDesign #safetytips

[koldwater @TechnicianEDU]

NEW: Website and Discounts Updated!

Check it out ...
https://t.co/HsSz3f2lAs

#electricaltraining #automationtraining #maintenancetraining

[koldwater @TechnicianEDU]

Instructor guide for using LogixPro™ programs within the newer PLCLogix® 500 simulator.
https://t.co/lglxsxUn78

[Don at BIN95.com @IndTraining]

With the growing renewable energy industry it is important for the novice to have a basic understanding of the VFD (Variable Frequency Drive). This article is a good start. https://t.co/Tg3QjbYRwA << See

#vfd #allenbradley #training

[Don at BIN95.com @IndTraining]

PLC Ladder Logic Random Number Generator This particular example is PLC ladder logic needed to generate a truer random number. (Exponentially more random)

Full article at https://t.co/LnmUp9wclf

#plc #plctraining #ladderlogic #automation #programming

[Don at BIN95.com @IndTraining]

Electrical Troubleshooting Testing Simulator software for training and testing. See https://t.co/jJe9fD6BFQ

This software covers three functional categories ...

Learning Electrical Troubleshooting
Teaching Electrical Troubleshooting
Testing Electrical Troubleshooting

[PLC Training Org @PLCTrainingOrg]

Thanks for the retweets @MarcLeVine_jobs .
You may also like and retweet this newly updated version https://t.co/l4a0aLrXYS of the free online electrical troubleshooting app/game.

[Don at BIN95.com @IndTraining]

Amazon cloud down takes down Canvas and thousands of other companies and institutions. That is why I have been telling #educators and #instructors they should only use cloud services as a last resort. Because of reliability and security concerns.

[koldwater @TechnicianEDU]

Operation of an induction electric motor. 7 of 7
The greater the difference between the stator magnetic field speed and the rotor speed (the ‘slip’) the more often the magnetic field cuts through the conductor and the greater the force generated on the conductor. #vocational #cet

[koldwater @TechnicianEDU]

Operation of an induction electric motor: 1 of
An induction electric motor works when AC power is turned on. Each phase of the alternating current goes into motor windings positioned around the outer stator.
#electricmotor #motor #electricity101

[koldwater @TechnicianEDU]

Operation of an induction electric motor. 6 of 7
In a motor, the rotor runs slower than the rotating
stator magnetic field. This means the magnetic field cuts the rotor conductors. The difference between the speed of the magnetic field and the speed of the rotor is called ‘slip’.

[Rosetta_Mic Drop! @RedRoseQueen1]

@beemerjean I talked about it with my 26 y.o. grandson who's a truck driver supporting 2 kids. We agree we need vocational and technical schooling paid by government for those NOT going to college. Fast food can still be done by kids in HS & students in college. It's a wise investment imo.

[Missy Young @MissyByte]

So cool of Alex Trebek and fam: @TheDoeFund has provided jobs, vocational training, education, and social services to more than 28,000 “underserved Americans” coping with addiction, homelessness, and a history of incarceration. https://t.co/nhkOA13qBg
