Byte Beast

[Byte Beast @bytebeast2006]

Applied Dual Port Dual Drive MZM for Optical Frequency Comb Generation. Provides much better results in terms of power and flatness than previous combination of IM and PM setup.

#ece #opticalcommunication #communication #thz

[Byte Beast @bytebeast2006]

Using Optisystem Software by Optiware for my Photonics/Optical Communication purpose. Make a Optical Frequency Comb Generator and then filtered required Teeths for further tasks, used various Modulators, Amplifiers, Filters, Source Generators for the task.

[Byte Beast @bytebeast2006]

Would be doing the course Electronics System Design by Prof. Ankur Gupta along side other stuff I am doing , same pattern of going through 1 lecture a day.

#electronics #ece #system #design

[Byte Beast @bytebeast2006]

Would be learning C++ DSA via Coder Army @rohit_negi9 decided to go through 1 lecture a day let things take time no issue. Might be sharing progress here...

#dsa #cpp #coderarmy

[Byte Beast @bytebeast2006]

Tried IR Receiver on ESP32 , I would map what each button on this remote means probably use it as a controller.

#arduino #esp32 #esp #arduinoprogramming #embedded #electronics

[Byte Beast @bytebeast2006]

Tried Bluetooth on my ESP, transferred text using Serial Bluetooth Terminal.

[Byte Beast @bytebeast2006]

Shifted to learning ESP32 , tried my first wireless control , controlling LED On/Off.

#esp32 #arduino

[Byte Beast @bytebeast2006]

Finally the day arrived when I can understandably replicate this Arduino Based Radar System. This was the thing that let me learn about Arduino and followed New Arduino Playlist by @pauljmcwhorter.

Thank You.

[Byte Beast @bytebeast2006]

A Distance Measuerer using HC-SR04 Ultrasonic Sensor.

[Byte Beast @bytebeast2006]

Made a Calculator using LCD.
#arduino @pauljmcwhorter

[Byte Beast @bytebeast2006]

Counting on LCD
#arduino

[Byte Beast @bytebeast2006]

Tried this offline but nevermind, used LCD.
#arduino

[Byte Beast @bytebeast2006]

Used 74HC595 for this Hexadecimal Flip Flop...
#arduino

[Byte Beast @bytebeast2006]

Logical Shift Using 74HC595.
#arduino

[Byte Beast @bytebeast2006]

Hexadecimal Counter using 74HC595.
#arduino

[Byte Beast @bytebeast2006]

Used 74HC595 for this Hexadecimal Flip Flop...
#Arduino @pauljmcwhorter

[Byte Beast @bytebeast2006]

Direction and Speed control of DC Motor using Joystick.
#Arduino

[Byte Beast @bytebeast2006]

Now used a Potentiometer to control DC motor speed.
#Arduino

[Byte Beast @bytebeast2006]

Controlled DC Motor using Tilt Swtich, though it is risky to take direct power from Arduino.
#Arduino

[Byte Beast @bytebeast2006]

Used Tilt Switch to switch between LEDs
#Arduino
