Top Tweets for #EngineeringDrawing
To my fellow professionals Engineers in the house,
What is your thought on this cantilever

An engineering drawing isn't just lines , it's a complete instruction manual for building something real.. 🤝👌 #EngineeringDrawing
#Day02
Congratulations to all students and faculty members for this excellent achievement.
#ProudMoment #CivilDepartment #EngineeringDrawing #AnnaUniversity #SudharsanEngineeringCollege #100PercentResults

Book: Straight lines, perfect circles 📐✨
Me after 3 attempts: Earthquake test passed 💀😂
Still writing ‘NEAT WORK’ on top and hoping for full marks 🤡📄
#EngineeringDrawing #StudentStruggles #EngineeringMemes #CollegeLife #ExamMemes #MechanicalEngineering #DrawingFail

Started this on Feb 13…
Completed on April 25 ✅
2 months. 62 Q&A.
Engineering Graphics (MU) — full thread 📚
If it helps even 1 student, worth it 🙌
#EngineeringGraphics
#CivilEngineering
#EngineeringStudents
#EngineeringProblems
#EngineeringDrawing
61) A regular pentagon of 25 mm side has its surface inclined at 30° to HP. One of its sides is parallel to HP and inclined at 60° to VP. Draw the projections of the pentagon.
#EngineeringDrawing
#EngineeringGraphics

58) A circle of 50 mm diameter is resting on HP at one end (A) of its diameter AC. The diameter AC is inclined at 30° to HP, and the top view of the circle is inclined at 45° to VP.
Draw the projections of the circle.
#EngineeringProblems
#EngineeringDrawing

56) Section of Solids
A right circular cone, base diameter 60 mm and axis 70 mm, rests on HP.
It is cut by a plane 45° to HP and ⟂ VP, intersecting the axis 35 mm above the base.
Draw the sectional top view.
#EngineeringDrawing
#EngineeringGraphics

53) A square pyramid, base 40 mm and axis 60 mm, rests on HP with one base edge parallel to VP.
It is cut by a plane ⟂ VP and 45° to HP, bisecting the axis.
Draw: Sectional TV, True Shape of Section & Development of Lateral Surface
#EngineeringProblems
#EngineeringDrawing

51) Projection of Plane
A hexagonal plate, side 25 mm, rests on one of its edges on HP.
The resting edge makes 45° with HP and the plane is 60° to VP.
Draw the projections of the plane.
#EngineeringDrawing
#EngineeringGraphics

48) Section of Solids
A cylinder, 40 mm diameter and 60 mm height, stands on HP with its axis vertical.
It is cut by a plane ⊥ VP and 45° to HP, intersecting the axis 30 mm above the base.
Draw FV, sectional TV and true shape of section.
#EngineeringProblems
#EngineeringDrawing

46) Projection of Solids
A pentagonal prism, base side 35 mm, forms a cone of height 70 mm in projection.
Its axis is inclined 45° to HP and 30° to VP.
Draw the projections of the solid.
#EngineeringDrawing
#EngineeringGraphics

43) Projection of Plane
A circle of 50 mm diameter rests on HP at a point on its circumference.
Its plane is inclined 45° to HP and 50° to VP.
Draw the projections of the circle.
#EngineeringProblems
#EngineeringDrawing

41) Projection of Plane
A rectangle 50 mm × 30 mm rests on HP on its longer side.
That side is inclined 45° to HP and the surface of the plane is 30° to VP.
Draw the projections of the plane.
#EngineeringDrawing
#EngineeringGraphics

38) Projection of Solids
A square prism is placed below XY.
Above XY its projections form a 60 mm rectangle.
The rectangle is then inclined at 50° and projected downward to obtain the final solid.
Draw the required projections.
#EngineeringProblems
#EngineeringDrawing

36) Orthographic Projection
Overall size:
Length – 100 mm
Height – 70 mm
Breadth – 40 mm
Draw FV, TV & LHSV using first angle projection.
#EngineeringDrawing
#EngineeringGraphics

33) Orthographic Projection (Section)
Overall size:
L = 170.5 mm, B = 60 mm, H = 60 mm
Object contains Ø60 & Ø30 circular features and R10 slot.
Draw FV, TV & RHSV and show sectional details.
#EngineeringProblems
#EngineeringDrawing

31) Projection of Points (Concept)
An object is placed in space and projectors (rays of light) fall orthogonally on projection planes.
Illustrate with a neat sketch how image views (projections) are obtained and show the four quadrants.
#EngineeringDrawing
#EngineeringGraphics

28) A square prism (base 50 mm, axis 50 mm) rests on HP with all base sides equally inclined to VP.
It is cut by a section plane ⟂ VP passing through: Left bottom corner & Top right corner of elevation.
Draw: FV, sectional TV, true shape
#EngineeringProblems
#EngineeringDrawing
