Top Tweets for #EngineeringGraphics
#Viveksir 🦣once said " சாதா Shirt ah டீ- shirt ah ஆக்கிட்டு போறானே...
#FrontView #Backview
#EngineeringGraphics
Enna SIR 🐘 appo Engineering um Tea um onnu than nu sollrengala?
Started this on Feb 13…
Completed on April 25 ✅
2 months. 62 Q&A.
Engineering Graphics (MU) — full thread 📚
If it helps even 1 student, worth it 🙌
#EngineeringGraphics
#CivilEngineering
#EngineeringStudents
#EngineeringProblems
#EngineeringDrawing
Free Engineering Graphics (Sem II) 📚
62 solved questions (MU)
Perfect for last-day revision
Save this thread before exams 👇
#EngineeringGraphics #MumbaiUniversity
That’s a wrap for Engineering Graphics (Sem II) 🏗️
62 Q&A covered 📚
Complete revision thread for students
If this helped you:
👉 Save & share with friends
More Civil Engineering content is coming soon…
What should I cover next? 👇
#EngineeringGraphics #CivilEngineering
61) A regular pentagon of 25 mm side has its surface inclined at 30° to HP. One of its sides is parallel to HP and inclined at 60° to VP. Draw the projections of the pentagon.
#EngineeringDrawing
#EngineeringGraphics
59) A rectangular object has:
Left side = 50 mm
Right side = 100 mm
Vertical height = 15 mm
The object is inclined at 30°.
Draw its isometric view.
#EngineeringGraphics
#CivilEngineering
56) Section of Solids
A right circular cone, base diameter 60 mm and axis 70 mm, rests on HP.
It is cut by a plane 45° to HP and ⟂ VP, intersecting the axis 35 mm above the base.
Draw the sectional top view.
#EngineeringDrawing
#EngineeringGraphics
54) Section of Solids
A square pyramid, base 40 mm and axis 60 mm, rests on HP with all base edges equally inclined to VP.
It is cut by a plane ⟂ VP and 45° to HP, bisecting the axis.
Draw the sectional top view.
#EngineeringGraphics
#CivilEngineering
51) Projection of Plane
A hexagonal plate, side 25 mm, rests on one of its edges on HP.
The resting edge makes 45° with HP and the plane is 60° to VP.
Draw the projections of the plane.
#EngineeringDrawing
#EngineeringGraphics
49) Section of Solids
A right circular cone, base diameter 60 mm and axis 60 mm, rests on HP.
It is cut by a plane 45° to HP and ⟂ VP, intersecting the axis 40 mm above the base.
Draw FV, sectional TV and true shape of section.
#EngineeringGraphics
#CivilEngineering
46) Projection of Solids
A pentagonal prism, base side 35 mm, forms a cone of height 70 mm in projection.
Its axis is inclined 45° to HP and 30° to VP.
Draw the projections of the solid.
#EngineeringDrawing
#EngineeringGraphics
44) Projection of Plane
A regular hexagon, side 25 mm, has one side in HP.
The opposite side is 30° above HP and the surface is 45° to VP.
Draw the projections of the plane.
#EngineeringGraphics
#CivilEngineering
41) Projection of Plane
A rectangle 50 mm × 30 mm rests on HP on its longer side.
That side is inclined 45° to HP and the surface of the plane is 30° to VP.
Draw the projections of the plane.
#EngineeringDrawing
#EngineeringGraphics
39) Section of Solids
A square pyramid
Base side – 40 mm
Axis – 60 mm
It rests on HP with one base edge parallel to VP.
Cut by a plane ⊥ VP and 45° to HP, bisecting the axis.
Draw sectional TV and true shape of section.
#EngineeringGraphics
#CivilEngineering
36) Orthographic Projection
Overall size:
Length – 100 mm
Height – 70 mm
Breadth – 40 mm
Draw FV, TV & LHSV using first angle projection.
#EngineeringDrawing
#EngineeringGraphics
34) Isometric View
An object has two sides inclined at 30°.
Left side = 30 mm
Right side = 60 mm
Vertical height = 40 mm
Construct the Isometric View of the object.
#EngineeringGraphics
#CivilEngineering
31) Projection of Points (Concept)
An object is placed in space and projectors (rays of light) fall orthogonally on projection planes.
Illustrate with a neat sketch how image views (projections) are obtained and show the four quadrants.
#EngineeringDrawing
#EngineeringGraphics
29) Orthographic Drawing
The Front View (FV) and Top View (TV) of an object are given.
Overall dimensions: 80 mm × 90 mm. Draw the Left Hand Side View (LHSV) using first angle projection.
#EngineeringGraphics
#CivilEngineering
26) Pentagonal prism, base side 30 mm and axis 50 mm, stands on HP on its base with one base edge ⟂ VP. It is cut by a section plane inclined 45° to HP passing through the midpoint of axis.
Draw: FV, sectional TV, sectional side view & true shape.
#EngineeringGraphics
23) Cone Resting on Generator
A cone of base diameter 40 mm and axis 50 mm rests on HP on one of its generators.
The generator makes an angle of 30° with VP.
Draw its projections.
#EngineeringGraphics
#CivilEngineering
