Martin Lass

Marketing Manager 3D ToF Imager @Infineon

[Denis Laskov 🇮🇱 @it4sec]

Hacking the AirTag tracking system: spoof an AirTag’s location by recording BLE broadcasts. 👨🏻‍💻🧳🌐📱😰

More details on:
LinkedIn: https://t.co/53pZmtakAL
Substack: https://t.co/fl7Y2iqIZ6

[Fazil @fazilabs]

Not a map of the Strait of Hormuz but the microscopic view of a coating failure on a test wafer during our initial development of a PFAS-free chemically amplified resist (CAR) for advanced node lithography. Image shows severe classic macroscopic dewetting and film thickness..

[ElectronicsNotes by Ian Poole @ElecNotes]

Looking for a massive current boost in your analogue circuit designs?

The Darlington Pair configuration is an incredibly elegant solution when a single bipolar transistor just can't deliver the gain you need to drive low-impedance or high-current loads.

By cascading two transistors—connecting the emitter of the first directly to the base of the second—the total current gain (hFE) becomes the product of the two individual gains:

If you pair two modest transistors with a gain of 50 each, you instantly achieve an overall current gain of 2,500!

Key Advantages:
* Ultra-high current gain: Ideal for power supplies, audio output stages, and display drivers.
* High input impedance: Minimises loading effects on the preceding circuit stages.
* Design flexibility: Available as single integrated components (like standard Darlington transistors or IC arrays) or easily built with discrete components.

Design Considerations & Trade-offs:
No circuit is perfect, and the Darlington configuration comes with specific trade-offs:
* Higher VBE drop: Because you are driving two base-emitter junctions in series, you need around 1.2V to 1.4V (for silicon) to turn the pair on.
* Higher saturation voltage: Typically around 0.7V, which can increase power dissipation in switching applications.
* Slower switching speeds: The output transistor can be slow to turn off because its base charge has no quick path to dissipate.

Pro-Tip: To combat slow turn-off times, it's good practice to include a base-emitter bypass resistor across the second transistor to help discharge that stored junction charge faster!

Want to dive deeper into the formulas, design attributes, and variations like the Sziklai pair? Read the full breakdown on my website - link in the comments.👇

#CircuitDesign #ElectronicsEngineering #AnalogueCircuits #ElectricalEngineering #HardwareDesign

[i2cjak @i2cjak]

these guys are more precise than heart surgeons btw

[Technology & Machines 👩‍💻⚙️ @logiclpd]

This 1960s IBM Selectric typewriter uses a spinning ball whilst typing characters.

[pongsagon vichit @MattDIYgraphics]

TinyGPU v3.0 is coming with a programmable Pixel Shader!!
Tested on FPGA and submitted to the #TinyTapeout May shuttle (~290k transistors).
This Chameleon demo is a tribute to the #GeForce 3, the first programmable GPU released 25 years ago. https://t.co/GCy7tmGfUA

[Chris Holt @Chrismholt]

@fishPointer You need a jewelry laser welder. Great for spot welding tasks. Seriously figure out how to try one out. They are almost magical in a lab when you are building small assemblies.

[Fazil @fazilabs]

Fairchild Semiconductor. Cornerstone of modern Silicon Valley whose founders - the "Traitorous eight" - left Shockley Semiconductor in 1957 due to management issues founded the company that pioneered the commercial production of silicon transistors and ICs. Unrelated: I Left ASML

[S.T.E.M Explorer @stemexplor]

Zero actuators. Zero sensors. 70% obstacle clearance.

[Harvin⚡️ @meemeyerHarvin]

Using the $1300 FPGA to emulate a $1.99 IC for your breadboard circuit

[Tom Dörr @tom_doerr]

Builds CNC machine from scratch

https://t.co/vbSeJilBpQ

[vixhaℓ @TheVixhal]

https://t.co/tmMaGWK4CM

[Fazil @fazilabs]

The single biggest hidden enabler of this jump isn’t the laser power scaling (which everyone expects) — it’s a new tin droplet pre-pulse shaping technique we’ve been quietly validating since Q3 2025.

[Aurelien @Aurelien_Gz]

i’m still trying to process this..

this is a fully functional 3d electric circuit simulator running in a browser

wizard » @austin_malerba

[RossRadio @cqcqcqdx]

There's gold in them thar circuit boards!
Honeywell computers in the 1970’s. Had a gold room that had a molten gold flow machine— river of gold.

[UHF Satcom 🇬🇧 📡 📻 @uhf_satcom]

RF magic.

[Fazil @fazilabs]

Zeiss SMT was key to both entities wrt to their mirror tech. The same science used to "hear" the universe is helping us "print" the future.

[Chris Holt @Chrismholt]

Never been so proud. My daughter’s first soldering is PERFECT.

[Jerry Giant @tty0x24]

Rate my layout.

[Fazil @fazilabs]

This @cleoabram short features LIGO mirrors (Gravitational Waves), called the most precise experiment ever built. Was asked how they compare to mirrors in ASML machines (Chip Making).
It’s a battle of giants: Extreme Stability vs. Extreme Atomic Flatness🧵
https://t.co/KGSxMBOmNR
