Multimeter Parts

This channel is about multimeters and multimeter parts—featuring meters, calibrators, and electronic test equipment worth fixing.

[Multimeter Parts @multimeterparts]

Agilent U1272A — Quick Specs
Power: 4 × AAA batteries (up to 300-hrs)
Fuses: 0.440A/1000V and 11A/1000V
Main Functions: AC/DC voltage & current, res., cap., freq., temp., data log & memory (10,000 points), relative mode, Decibel (dBV), smooth function, backlight, and more.

[Multimeter Parts @multimeterparts]

Agilent U1272A True RMS Multimeter — Reference
Test equipment worth fixing.
Quick Specs, cleaning/repair tips, and replaceable parts

[Multimeter Parts @multimeterparts]

Fluke 189 True RMS Multimeter — Quick Specs

Power: 4 × AA alkaline batteries (typical 72-hour life with backlight off; extended battery pack available for longer logging sessions).
Fuses: 11 A / 1000 V and 440 mA / 1000 V (fast-acting; quick-access door without breaking calibration seal).
Main Functions: True-RMS AC/DC voltage & current (100 kHz bandwidth), 50,000-count dual display with analog bar graph, resistance & conductance, capacitance (up to 50 mF), frequency & duty cycle/pulse width, temperature (type-K thermocouple), MIN/MAX/Avg with timestamp, peak capture (250 µs), data logging & memory (up to ~995 events + 100 saved readings on the 189), relative mode, dB/dBm, AutoHOLD, backlight, and more.

[Multimeter Parts @multimeterparts]

Fluke 189 True RMS Multimeter — Reference Thread 🛠️

Test equipment worth fixing (and worth having).

All Quick Specs, cleaning/repair tips, parts recommendations, and updates for this model will live here.

Start with the Quick Specs 👇

Which repair or feature should we cover next for this meter? Reply below 👇

#Multimeter #TestEquipment #Fluke189

[Multimeter Parts @multimeterparts]

Ecom Ex-DM1000 Intrinsically Safe Multimeter — Quick Specs

Power: 9-Volt block battery according to IEC 6LR61 (alkaline)
Fuses: 0.440A/1000V and 10A/1000V fast acting fuses
Main Functions: Main functions AC/DC voltage and current, resistance, capacitance, frequency + more.

[Multimeter Parts @multimeterparts]

Ecom Ex-DM1000 Intrinsically Safe Multimeter — Reference Thread 🛠️

Test equipment worth fixing (and worth having).

All Quick Specs, cleaning/repair tips, parts recommendations, and updates for this model will live here.

Start with the Quick Specs 👇

Which repair or feature should we cover next for this meter? Reply below 👇

#Multimeter #IntrinsicallySafe #Ecom #ElectronicTestEquipment

[Multimeter Parts @multimeterparts]

Fluke 27 II Rugged Digital Multimeter — Quick Specs🪛
Power: Three AA batteries
Fuses: 0.440A/1000V and 10A/1000V fast acting fuses
Main Functions: DC and AC voltage, DC and AC current, resistance, capacitance, frequency + more.

[Multimeter Parts @multimeterparts]

Fluke 27 II Rugged Digital Multimeter — Reference Thread 🛠️

Test equipment worth fixing (and worth having).

All Quick Specs, cleaning/repair tips, parts recommendations, and updates for this model will live here.

Start with the Quick Specs 👇

What's your experience like with this meter? Reply below 👇

#Multimeter #Fluke27ii #ElectronicsRepair #TestEquipment

[Multimeter Parts @multimeterparts]

Omega HHM29 — Quick Specs 🛠️
Power: 9-volt battery
Fuses: 0.5A/250V and 10A/600V fast blow ceramic
Main Functions: DC/AC voltage & current, resistance, capacitance, frequency, temperature, inductance + more.

[Multimeter Parts @multimeterparts]

Omega HHM29 Digital Multimeter Thermometer — Reference Thread 🛠️

Test equipment worth fixing (and worth having).

All Quick Specs, cleaning/repair tips, parts recommendations, and updates for this model will live here.

Start with the Quick Specs 👇

Which repair or feature should we cover next for this meter? Reply below 👇

#Multimeter #OmegaHHM29 #thermometer #ElectronicsRepair #TestEquipment

[Multimeter Parts @multimeterparts]

Fluke 23 Series II Multimeter

[Multimeter Parts @multimeterparts]

This is a Fluke 179 multimeter, and it's worth fixing.
Here are some replaceable parts that fix most issues most of the time: Fuses, Screws, Elastomeric Connectors, LCD Mask, Top & Bottom Case, Switch Knob, Switch Pad, & LCD https://t.co/K76HQNftso

[Multimeter Parts @multimeterparts]

Greenlee DM-810 True RMS Multimeter

[Multimeter Parts @multimeterparts]

Altek 422 Universal Thermocouple Calibrator

[Multimeter Parts @multimeterparts]

Hewlett Packard HP 34401A Multimeter

[Multimeter Parts @multimeterparts]

@CinqCharles Thank you for your interest. We don't have this one available for sale, but we'll make it a point to note if a multimeter is for sale on future posts if applicable.

[Multimeter Parts @multimeterparts]

Tektronix TX3 True RMS Digital Multimeter

[Multimeter Parts @multimeterparts]

Fluke 87 True RMS Multimeter
