MN2-4 KMSS, "Dutch Crops" taken from the eastpass
60 dgr. max elv. so the signal was not strong because of the thermal noise comming from the houses it just flew over..
the good news is: Lime at 75 MSPS no sampledrops !
a next time i'll try 79 MSPS....west pass i hope :)
Today's helical tuning made me close in a bit
at HRIT. i got a some extra chunks at least.
the rest will have to be taken care of
by a better LNA..
it's on it's way ( i hope :)
@TechSDR1 Awesome you're doing great already,
and it will get hughe for sure !
i will get back to X-band again when all L-band projects are finished..though i enjoy doing some L-band again i must say...
A bit of progress signal-wise, 7.9 DB now at L3's LRIT.
this time a config with ~7.5 windings (still not cut)
total lenght just 95 mm, at the adjustable Helixfeed
yes.. it's hard to keep an equal winding-distance mechanical --> w.i.p still...
Elektro L3 at 16:42 LT
7.7 DB with the helical without the sunnoise,
it has officially beaten my patchfeed now :)
still todo : trim ( cut back ) the last winding, mm by mm
to optimize (or screw up :) the S/N..
enjoy Europe's citylights ..๐ฏ๏ธ๐ฏ๏ธ๐ฏ๏ธ
A quik check with the helicalfeed on HRPT:
MN2-4's low Atlantic pass, showing the first
snow at N- England and the Scottisch higlandsโ๏ธ
(cyan color = crystal detection)
peak @ 19 DB, so that's pretty decent for my dish..
Elektro L3 LRIT at 13:42 LT,
after the rainshowers, tuning continues,
having a bit more signal then the Patchfeed now...
distance and diameter can now be easily adapted by sliding and turning...rough version still
