𝐁𝐑𝐄𝐀𝐊𝐈𝐍𝐆: $MRVL 𝐌𝐚𝐫𝐯𝐞𝐥𝐥 𝐭𝐨 𝐃𝐞𝐬𝐢𝐠𝐧 $GOOGL 𝐆𝐨𝐨𝐠𝐥𝐞 𝐍𝐞𝐭𝐰𝐨𝐫𝐤𝐢𝐧𝐠 𝐂𝐡𝐢𝐩 𝐨𝐧 $INTC 𝐈𝐧𝐭𝐞𝐥 18𝐀 𝐢𝐧 𝐚 𝐌𝐚𝐣𝐨𝐫 𝐖𝐢𝐧 𝐟𝐨𝐫 𝐈𝐧𝐭𝐞𝐥 𝐅𝐨𝐮𝐧𝐝𝐫𝐲, 𝐩𝐞𝐫 𝐅𝐮𝐧𝐝𝐚 𝐀𝐈

Funda AI reports that Marvell will design a custom networking chip for Google. It will be fabricated on Intel’s advanced 18A (or 18AP) process node, with mass production ramping by end of 2027. This chip will pair with MediaTek’s Humufish (Google’s next-gen TPU v8e design).

This is a clear signal of Google’s multi-vendor strategy in full swing. Diversifying design partners, while tapping Intel Foundry for cutting-edge manufacturing.

This builds on reports from April of Google in talks with Marvell for AI inference chips, including a memory processing unit to complement TPUs and a new inference-optimized TPU.

[Muhammad Zuhair @mzuhair123]

Thank you @Intel_Foundry, but I'll take it from here.

EMIB-T: The Only Advanced Packaging That Matters

For my audience, they are pretty aware of the fact that I have an EMIB-T post up, talking about TSVs, MIM capacitors, and how reticle-scale comes into play. I'll drop the link in the comments :)

But this isn't the interesting part; rather, specifically, Intel is talking about technologies that are the emerging avenues:

- Enabling over 12 Gb/s HBM4e with EMIB-T
- Package architectures for hyper-large form-factors for AI and HPC

Co-Packaged Optics for Improved Bandwidth

-High-performance detachable edge optical
- V-groove-based edge coupling glass coupler interface

Hybrid Bonding

- Die distortion in die-to-wafer hybrid bonding
- Ultra-low temperature hybrid bonding for die-to-wafer scaling

$INTC

[Diamond Hanz, CFA (NFA) 💎 @diamhanz]

#Intel’s 18A node math is wild.
• Foundry wafer cost: ~$22k
• Yields: ~60% (Past the danger zone)
• Finished chip revenue: $65k–$90k+ per wafer
That’s a $40k–$70k gross profit spread per wafer being used to fund Intel's massive long-term turnaround strategy. $INTC

[SemiAnalysis @SemiAnalysis_]

With the introduction of the TPUv8t, their new training focused TPU, Google unveiled a new scale-out network architecture called Virgo. Virgo is able to interconnect up to 134,400 chips with up to 47 Pbps of non-blocking bi-sectional bandwidth. (1/4)🧵

[Elon Musk @elonmusk]

Hadamard thought in image space

[Arijit Bandyopadhyay @arijitban]

PHISON Electronics Corp. - Phison Collaborates with Intel to Bring Larger Local AI Workloads to Intel AI PC Platforms https://t.co/XAfpOrMUAa

[Muhammad Zuhair @mzuhair123]

Finally, @SemiAnalysis_ talks about this:

"Intel Foundry's EMIB plus 18A-P/T is positioned as a multi-billion-dollar external franchise into 2028. New entrants still pushing into foundry. Rapidus (2nm/1.4nm), Tata (mature), Huawei (Tau Scaling), and Tesla-SpaceX Terafab targeting 1M wafers/month across logic, memory, and packaging.  The foundry industry is now three markets."

$INTC Q126 growth tells a lot about the foundry momentum, and if you have been following my work, I am sure this data is nothing new :)

[LMSYS Org @lmsysorg]

🚀 New blog: Heterogeneous CPU + GPU EPD Disaggregation to Boost VLM Serving, with Intel Xeon CPUs offloading vision encoding to cut TTFT and boost throughput.

Vision encoding is the bottleneck in image-heavy VLM serving. Offloading it to CPUs changes that. By using SGLang EPD disaggregation + Dynamo device-aware weighted router + @Intel AMX on Xeon 6747P, we achieved:
✅ 1.2-1.3× lower P99 TTFT & higher request throughput ✅ 1.3-30× lower P99 TPOT
✅ Extra ROI on top of pure GPU EPD disaggregation, at near-zero added cost

Thanks to @inteldevs for the collaboration on this!

[Arijit Bandyopadhyay @arijitban]

Source: Neowin https://t.co/Ll1l6goLLs

[Ben Pouladian @benitoz]

Jensen put a 1 petaflop AI machine on your desk

RTX Spark
Blackwell GPU + 20 core Grace CPU built with MediaTek
128GB unified memory at 600 GB/s

In January I said Apple owned the edge
NVIDIA just answered at the desk

The Edge Token Factory
$NVDA
https://t.co/KoATlVzmgK

[Muhammad Zuhair @mzuhair123]

$INTC Crescent Island Is Here, And It's The First 18A-P Product to Offer Up to a Whopping 480GB LPDDR5X Memory For High-Speed Inference

Intel's first mainstream datacenter GPU launch, the Crescent Island, is here, and we last saw this SKU at Intel Tech Tour. The fascinating part about this launch is Intel's decision to mount loads of LPDDR5X memory, higher than AMD's Instinct MI450X and Vera Rubin.

At the same time, Crescent Island will be a PCI Express add-in card with a 350W power target, placing its power and thermal requirements close to products like Nvidia's RTX Pro 5000 Blackwell card.

Intel describes Crescent Island as "coming soon" and has touted a second-half 2026 launch for the platform, so we'll presumably learn more about the product and the ecosystem building around it as we progress further into the year.

[Alex @Alex_Intel_]

Intel Crescent Island will do pre fill for the SambaNova RDU rack

SambaNova has relucked back into a good architecture for the current models

Intel not mentioning the node of Crescent Island implies that it's N2P

[ImNotHarsh | 📈💸 @imnotharsh]

JUST IN: $INTC Intel highlighted integration/support for $NVDA Nvidia Dynamo with its upcoming Crescent Island AI inference GPU (Xe3P architecture, up to ~160GB LPDDR5X memory, sampling H2 2026).

Intel is contributing to Dynamo to enable heterogeneous AI inference, mixing different hardware (e.g., Intel GPUs/CPUs and Nvidia GPUs) in the same cluster.

This allows systems where, for example, Nvidia GPUs handle prefill and Intel accelerators (or vice versa) handle decode, optimizing for cost, power, and performance-per-watt.

Intel’s Crescent Island is positioned as a power-efficient, air-cooled inference GPU using cheaper/high-capacity LPDDR5X (to avoid HBM shortages/costs). Dynamo helps orchestrate it alongside Nvidia hardware via NIXL for data transfers.

Intel Xeon 6 CPUs are host options in Nvidia DGX systems, and support for heterogeneous setups in AI factories.

[Due Calli @Intellionaire]

The Intellionaire Ep. 33: Intel, GaN & Power Semis

How $INTC fits into the Power Semi & RF arena, including the possible tie-in with SpaceX!

https://t.co/TJeoUc6daZ

[Dan Nystedt @dnystedt]

Nvidia CEO Jensen Huang is expected to reveal fresh details about the upcoming Feynman GPU, and new Arm-based N1X chip for Windows PCs today during his GTC Taipei keynote speech, media report, noting Nvidia, Arm and Microsoft all posted “New Era of PC” messages on their social media platforms. $NVDA $ARM $MSFT https://t.co/iVjNHWS6jB

[SemiAnalysis @SemiAnalysis_]

Ever wonder what L11 diags means? Let's break it into two components: L11 and diags. (1/5)

[McKinsey & Company @McKinsey]

What could be the next trillion-dollar industries?

Building on our research into the 12 arenas of future growth, we’ve identified 18 emerging industries showing early signs of outsized potential. https://t.co/H4mRUnXfaH

[Arijit Bandyopadhyay @arijitban]

HUAWEI has presented the Tau (τ) Scaling Law, a new principle for guiding the future development of the semiconductor industry by utilizing LogicFolding. https://t.co/cMdypx7gE6

[Arijit Bandyopadhyay @arijitban]

https://t.co/8l6bltb5jZ

[Shishir @ShishirShelke1]

Nvidia’s new ARM-based chips: N1 & N1X specs LEAKED 🚨

N1X:
- Up to 20 CPU cores
- Up to 48 SMs GPU (6144 CUDA cores)
- Up to 128GB LPDDR5X memory
- 45W to 80W TDP

N1:
- Up to 12 CPU cores
- Up to 20 SMs GPU (2560 CUDA cores)
- 18W to 45W TDP

The full N1X uses the same configuration as GB10 used in DGX Spark.

First Windows laptops powered by these chips are expected to debut next week.
