[Jaycon @jayconsystems]

One mold. One massive plastic fan blade! 🤯

Watch this satisfying injection molding process in action.

#InjectionMolding #PlasticManufacturing #Jaycon

[Jaycon @jayconsystems]

Ever wondered what happens after you send your Gerber files to a PCB factory?

CNC drilling, lamination, copper plating, solder mask, AOI and flying probe testing. Every step inside a five story PCB fab:

https://t.co/cirQS2NDMD

#PCBFabrication #PCBManufacturing #jaycon

[Jaycon @jayconsystems]

Great parts start with the right tool.
Upload your CAD for an instant quote at https://t.co/VPWurL15KW

#InjectionMolding #ProductDevelopment #jaycon
[5/5]

[Jaycon @jayconsystems]

Your T1 parts look good. That’s not enough. Here’s what experienced teams check before approving injection molded samples.
[1/5] 🧵

[Jaycon @jayconsystems]

Test the process window. Stable across shots? Flash near limits? Fit with mating parts? Cosmetics under spec lighting?
[4/5]

[Jaycon @jayconsystems]

Check every cavity. On multi cavity tools, one good cavity proves nothing. Review samples from each.
[3/5]

[Jaycon @jayconsystems]

Measure after parts stabilize. Fresh parts keep shrinking, so dimensions taken right off the press can mislead you.

[2/5]

[Jaycon @jayconsystems]

From plastic brushes to hundreds of molded caps! 🤯

A satisfying look at injection molding and everyday plastic manufacturing.

#InjectionMolding #PlasticManufacturing #Jaycon

[Jaycon @jayconsystems]

That satisfying moment when an injection mold opens! 🤯

Watch a green plastic component come out of an industrial molding machine.

#InjectionMolding #PlasticManufacturing #Jaycon

[Jaycon @jayconsystems]

One extra screw after product assembly? 💀

An engineer's worst nightmare! Would you take it apart?

#EngineeringHumor #MechanicalEngineering #Jaycon

[Jaycon @jayconsystems]

Metal, flexible, or MASSIVE prototypes? 🤯

Inside a Dongguan factory exploring large-scale 3D printing and rapid prototyping!

Which would you choose?

#3DPrinting #RapidPrototyping #Manufacturing #Jaycon

[Jaycon @jayconsystems]

Parting lines and ejector pin marks have to go somewhere. Mark your cosmetic surfaces so they stay off the side your customer sees.

Instant injection molding quote: https://t.co/VPWurL15KW

#InjectionMolding #ProductDesign #jaycon

[Jaycon @jayconsystems]

A laser turning liquid resin into solid 3D-printed parts? 🤯

See SLA 3D printing technology in action, layer by layer!

#SLA3DPrinting #ResinPrinting #AdditiveManufacturing #Jaycon

[Jaycon @jayconsystems]

Why do injection molds cost so much and take so long?

Hardened steel, CNC machined, ground, EDM cut, polished and hand fitted. Weeks of work so a press can make a part every 30 seconds.

Get an instant injection molding quote: https://t.co/FZw53Yvez6

#InjectionMolding #Jaycon

[Jaycon @jayconsystems]

Small adjustments, big results! ⚙️

Inside a China factory, where industrial machines are fine-tuned for local materials to improve manufacturing precision.

#Manufacturing #MachineOptimization #Engineering #Jaycon

[Jaycon @jayconsystems]

Your plastic choice is costing you.

ABS for housings. Polycarbonate for impact and clear parts. Polypropylene for living hinges. Nylon for gears and wear.

Upload your CAD and get an instant injection molding
quote: https://t.co/VPWurL15KW

#InjectionMolding #jaycon

[Jaycon @jayconsystems]

What keeps a 3D printing factory running smoothly? ⚙️

A behind-the-scenes look at machine maintenance and factory operations!

#MachineMaintenance #3DPrinting #Manufacturing #Jaycon

[Jaycon @jayconsystems]

What if you could FEEL your 3D designs? 🤯

See how robotic arms and haptic feedback are changing 3D modeling and rapid prototyping.

Would you try it?

#HapticTechnology #3DModeling #Robotics #Jaycon

[Jaycon @jayconsystems]

Most undercuts are avoidable.

A through hole or a repositioned snap often removes the need for a slide entirely. Fix it in CAD, not after the tool is cut.

[5/5]

#injectionmolding #DFM #jaycon

[Jaycon @jayconsystems]

One feature can double your mold cost.

Undercuts, explained.

🧵[1/5]

[Jaycon @jayconsystems]

Undercuts force the mold to move sideways.

Cams and slides release the feature before ejection. More steel, tighter fitting, longer cycles. You pay once in tooling and again on every part.

[4/5]
