[PCB Partner @PCBPartner]

Our multi-factory spread means we can handle some pretty complex #PCB prints. If you need between 1-40 layers, contact us!

#pcbdesign #printedcircuitboard #engineers

[PCB Partner @PCBPartner]

How many electrical test methods can you name that #PCBmanufacturers use?

#makers #makerspaces #electricalengineering

[PCB Partner @PCBPartner]

Shout out to all the amazing thermal engineers you know! Without you, we wouldn't get to have so much fun playing with electronics😊
#ThermalEngineerDay

[PCB Partner @PCBPartner]

What advice would you have wanted when just starting out in #pcbdesign? 🤔👇

#makers makerspace #engineer #PCB

[PCB Partner @PCBPartner]

How do you check the quality of an SMT stencil? 🤔
Look at 👇
1) The shape of the openings
2) The size of the openings
3) The width-thickness ratio
4) The area ratio

✅ Did your last check all the boxes?

#smtstencil #pcba #pcbdesign

[PCB Partner @PCBPartner]

What does my most frequently used emoji list say about me?

Possibly that I need to petition for a poop emoji that isn't so gd cheerful. 🙃

Or I'm a flirt that 💩's a lot (good bowel function, maybe not good manners)

What is your most frequently used emoji? 👇

#WorldEmojiDay

[PCB Partner @PCBPartner]

Fast. Easy. Low-cost.
^3 things you'll love about our instant quotation page. Available for 1-10 layers FR4, aluminum #PCB, and SMD stencil. Get your quote in seconds & order from one of our many factories today 👇👇https://t.co/NEttYDELou

#pcbmanufacturer #makerspaces #makers

[PCB Partner @PCBPartner]

💭 Minimize the amount of 0 ohm resistor jumpers used in your board work, it could become a problem in higher frequency applications as they create unwanted noise in your project!

The more you know! 🧠

#PCB #pcbdesign #pcba #arduino

[PCB Partner @PCBPartner]

Our free iPCB-DFM #software has powerful features such as quick panalization, #PCB simulation view, direct Gerber editing, and more. It can even help you count how many SMD pads are in your #pcbdesign. Download it now to check your design 👇https://t.co/OCeEmMqLc4
#Engineering

[PCB Partner @PCBPartner]

Dubbed "The Gauntlet", this sick glove uses conductive contact points to turn your hand into a keyboard. Props to nitr1c over on hackaday for this cool use of Arduino https://t.co/yDv3S9EzJP

[PCB Partner @PCBPartner]

You may know one of the primary testing methods is an AOI test, but do you know what it is and what it stands for? 🤔

Automated Optical Inspection uses cameras, lights and visual computers to detect errors, enabling manufacturers to produce #PCB to required standards

#pcba

[PCB Partner @PCBPartner]

6. Run the Design >> Update Schematic command to push the footprint and annotation changes back to the schematic
7. Remove all the unused jumper components from the schematic

#pcbdesign #kincad #eagle

[PCB Partner @PCBPartner]

7 easy steps 💡 to make connections with jumper wires in your PCB Software

1. Drag the jumper assembly into position
2. Include the required footprint name in the memory occupancy name field

Find the rest in the comments below 👇👇👇

[PCB Partner @PCBPartner]

3. Enter a suitable ID string in comment field of component dialog box for the BOM
4. Place the jumper in the desired position
Double-click to edit one of the pads and select the desired net name from the Network drop-down list

[Gregory Knauff @gregoryknauff]

Received my Christmas PCBs from @PCBPartner! Hopefully the circuit works well🤞

[PCB Partner @PCBPartner]

It’s #WorldMusicDay, drop us the name of a song from your country! 🎶
🍎 Xiaopinguo by Chopstick Brothers was everywhere in China in 2014 and the MV is wild. Thank us later. https://t.co/lEZQXvsgXa

[PCB Partner @PCBPartner]

Receiving an SMT Stencil for the first time? This is what you should check:

- does the thickness and size of the steel mesh opening match requirements?
- is the frame size correct?
- is the marking complete?
- is it level?
- how is the tension?

#pcbdesign #smtstencil #pcba #pcb

[PCB Partner @PCBPartner]

📣 Announcing 📣 iPCB-DFM Intelligent Design for Manufacturing Software for #PCBdesign. Save time on your #PCB designs - automatically find potential production issues before you send it off to the factory Download today https://t.co/OCeEmMqLc4

#electricalengineering #makers

[PCB Partner @PCBPartner]

#ProTipThursday When designing #PCBs, if you know that your final application will be hot (e.g. LEDs), opt for Aluminum to draw heat away from key components and increase their longevity

Get an instant quote for Aluminum 👇https://t.co/pV9NBlOGN6

#pcbdesign #makers #engineering

[PCB Partner @PCBPartner]

We’re celebrating our group’s 25th Anniversary this month! Throughout June, save up to $100 USD on your #PCB orders
👉 https://t.co/EqrrX35OFI
#promotion #electronics #electricalengineering
