Simulation Trends

Interested in 3D numerical simulation trends

[Jake Fitzgerald @earthtojake]

text-to-cad v0.5, just in time for Astra

- generate STEP, STL, GLB, 3MF, DXF files with code
- runs locally as a library of agent skills
- 100% open source and free

have fun mechies

[Bradley Rothenberg @brad_rothenberg]

Guénaël on our european team built a CCA design explorer that runs openfoam straight from ntop

ntop ML orchestrates the sweep while our openfoam plug-in is used for implicit interop, all runable / tunable via LLMs and packaged up into a design explorer dashboard for us humans to review

[nTop @nTopology]

nTop geometry feeding directly into @ANSYS Discovery, tied together in an automated workflow via OptiSLang. Setup takes 30 minutes. Once. Every run after that is near-zero overhead.

📹Video by Ansys, Manipulating the Geometry & Ansys Inside Discovery

[3DS SIMULIA @3DS_SIMULIA]

POV: Us rolling into the weekend with innovative tire designs thanks to simulation. 🚘😎

[Bradley Rothenberg @brad_rothenberg]

my dad just had a knee replacement & the implant was designed using @nTopology -- crazy

[Jousef Murad @Jousefm2]

⚡CFD simulation of wind buffeting on a Triumph Motorbike by TotalSim⚡

Transient DES CFD simulation of flow around a Triumph motorcycle and rider. Analysis used to help reduce buffeting upon the rider.

[Jousef Murad @Jousefm2]

⚡Impact of Large-Scale Structures on the Flow Around a Transonic High-Pressure Turbine Vane⚡

In this video, a high-resolution large-eddy simulation of a transonic HPT vane operating at realistic Reynolds and Mach numbers is shown.

[Prof Jesse Capecelatro @jesse_caps]

Curious about the math/physics involved with simulations like these? Tomorrow (Thurs 1/13) I will be giving a talk on modeling compressible gas-particle flows @NASA_NAS Advanced Modeling and Simulation (AMS) Seminar Series. Come on by! https://t.co/dtzKg68zMA

[Journal of Fluid Mechanics @JFluidMech]

Getting the ducks in a row🦆: “Yuan et al. (https://t.co/H5KrkTipM1) consider whether, by organising themselves optimally, ducklings in a row behind a mother duck can reduce, eliminate or even reverse their individual wave resistance.” Focus on Fluids https://t.co/YRan6k3MeP

[Takis Tsoutsanis @TakisCFD]

Excited to win the ARCHER2 2021 video competition with the following video which is the result of collaborative research using @ucns3d with colleagues at @CranfieldUni , @cranfieldaero enabled by @ARCHER2_HPC @EPCC @EPSRC @UKRI

[Journal of Fluid Mechanics @JFluidMech]

Simulations reveal that ducklings swimming in a single-file formation behind the parent can achieve a wave-riding benefit whereby the wave drag turns positive. Gives a new meaning to "get your ducks in a row" 🦆@JFluidMech #dynamic #equilibrium #swimming https://t.co/HUmZXhhCcV

[Journal of Fluid Mechanics @JFluidMech]

What about the flow above an espresso cup? Check out this research on reconstructing this nearly `hidden' flow. https://t.co/0mQTyQiM2R (open access for a limited time) #InternationalCoffeeDay #fluidmechanics #neuralnetworks #pinns #schlieren #tomography @flow_journal @JFluidMech

[Journal of Fluid Mechanics @JFluidMech]

Efficient, consistent mixing of two fluids is important in many industrial processes. Numerical simulations show that optimal stirring strategies have unusual motions, which differ from a simple circular path. https://t.co/X7aVSotQrg #mixing #optimization #physics #math

[DCS Computing GmbH @dcs_computing]

This represents a coupled CFD-DEM simulation of a single-screw extruder transporting and melting polypropylene granules (particles: white spheres, molten plastic: purple iso-surfaces).

#SimulationFriday #SimulationSoftware #CAE #aspherix #cfdemcoupling

[Chennakesava Kadapa @chenna1985]

I have not found any interesting examples for Hyper viscoelastodynamics problems.
Setting up one has been challenging.

Finite strains ✅
Incompressibility ✅
Viscoelastic model ✅
Elastodynamics ✅
Generalised-alpha scheme ✅

#FEM #Mechanics #SimulationFriday

[DCS Computing GmbH @dcs_computing]

Coupled CFD-DEM simulation of a mold flow. Fibers are inserted together with the fluid and start aligning with the flow pattern.

#SimulationFriday #SimulationSoftware #CAE #aspherix #cfdemcoupling

[Tammam Bakeer @TammamBakeer]

Which #FEM #software more capable to #model the post failure behavior of reinforced #concrete #construction?
To answer this #question, a reinforced concrete #beam has been simulated under bending, up to #collapse, in three FEM software, namely: #ANSYS, #ABAQUS, and #LSDYNA.

[COMSOL @COMSOL_Inc]

Fast fact: The #FoodSector is responsible for 37% of greenhouse gas emissions.

1 company is using simulation to design energy-efficient food transportation vehicles.

Here are 7 other examples of how simulation is being used to help the #environment: https://t.co/tcah7lsi05

[Prof. Feynman @ProfFeynman]

The difference between information and knowledge:

[COMSOL @COMSOL_Inc]

Q: How does crêpe making differ from typical interactions between substrate kinematics and a liquid layer?

A: https://t.co/MZkZ1NGsa3
